GIGABYTE B760M E Motherboard - Supports 14th Gen. Intel Core CPUs, 6+1+1 phases VRM, up to 7200MHz DDR5 (OC), 2xPCIe 4.0 M.2, 1 GbE LAN, USB 3.2 Gen 1

Name: GIGABYTE B760M E Motherboard - Supports 14th Gen. Intel Core CPUs, 6+1+1 phases VRM, up to 7200MHz DDR5 (OC), 2xPCIe 4.0 M.2, 1 GbE LAN, USB 3.2 Gen 1
Brand: Gigabyte
SKU: B760M E
Price: 92.43 EUR
Availability: InStock

Motherboards

92.43 € VAT included

In stock · 8

GIGABYTE B760M E Motherboard - Supports 14th Gen. Intel Core CPUs, 6+1+1 phases VRM, up to 7200MHz DDR5 (OC), 2xPCIe 4.0 M.2, 1 GbE LAN, USB 3.2 Gen 1, Intel, LGA 1700, Intel® Celeron®, Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel..., LGA 1700, DDR5-SDRAM, 128 GB

Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge

Supports Intel Core 14th/ 13th /12th processors
Unparalleled Performance: Hybrid 6+1+1 Phases Digital VRM Solution
Dual Channel DDR5: 2*DIMMs XMP Memory Module Support
Next Generation Storage: 2*PCIe 4.0 x4 M.2 Connectors
EZ-Latch: PCIe 4.0x16 Slot with Quick Release Design
Fast Networks: GbE LAN
Extended Connectivity: Display Port, HDMI, D-Sub
Smart Fan 6: Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP

Specifications

Features
Battery type	CR2032
Warranty	36 mo.
Country of origin	China
HDCP
Wi-Fi
Line-in
BIOS type	UEFI AMI
Audio chip	Realtek ALC897
RAID levels	0, 1, 5, 10
ACPI version	5.0
Cooling type	Passive
Ethernet LAN
HDMI version	2.1
RAID support
Component for	PC
Microphone in
TPM connector
Battery weight	3 g
LAN controller	Realtek RTL8111H
Product colour	Dark brown
DirectX version	12.0
Memory channels	Dual-channel
BIOS memory size	128 Mbit
Processor socket	LGA 1700
CPU fan connector
Clear CMOS jumper
Headphone outputs
Memory slots type	DIMM
Power source type	ATX
Unbuffered memory
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Maximum resolution	4096 x 2160 pixels
RGB LED pin header
USB 2.0 connectors	2
12V power connector
DisplayPort version	1.2
HDMI ports quantity
Motherboard chipset	Intel B760
Serial port headers
PC health monitoring	Fan, Temperature, Voltage, Water cooling
S/PDIF out connector
Audio output channels	7.1 channels
DisplayPorts quantity
Front panel connector
Number of memory slots	2
Processor manufacturer	Intel
Supported memory types	DDR5-SDRAM
USB 2.0 ports quantity	2
Ethernet interface type	Gigabit Ethernet
Maximum internal memory	128 GB
Motherboard form factor	micro ATX
Number of M.2 (M) slots	2
Number of battery cells
1st M.2 largest key size	2280
2nd M.2 largest key size	2280
Number of HDDs supported	4
Ethernet LAN (RJ-45) ports
Lithium weight per battery	0.07 g
Motherboard chipset family	Intel
VGA (D-Sub) ports quantity
Compatible processor series	Intel® Celeron®, Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel Core i5 12th Gen, Intel Core i5 13th Gen, Intel Core i5 14th Gen, Intel Core i7 12th Gen, Intel Core i7 13th Gen, Intel Core i7 14th Gen, Intel Core i9 12th Gen, Intel Core i9 13th Gen, Intel Core i9 14th Gen, Intel® Pentium® Gold
EPS power connector (8-pin)
Front panel audio connector
Supported processor sockets	LGA 1700
ATX Power connector (24-pin)
Number of CPU fan connectors
Number of RGB LED pin headers
Number of SATA III connectors	4
Supported memory clock speeds	7200,7000,6800,6600,6400,6200,6000,5800,5600,5400,5200,4800,4000 MHz
Supported storage drive types	HDD & SSD
PCI Express x1 (Gen 3.x) slots
PCI Express x16 (Gen 4.x) slots
Maximum internal memory per slot	64 GB
Number of chassis fan connectors	2
Number of storage drives supported	6
Products per shipping (inner) case	1 pc(s)
Supported memory clock speed (max)	7200 MHz
Supported storage drive interfaces	M.2, SATA III
Windows operating systems supported	Windows 10 x64, Windows 11 x64
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1st M.2 highest PCI Express generation	4.0
2nd M.2 highest PCI Express generation	4.0
Number of EPS power connectors (8-pin)
Parallel processing technology support	Not supported
System Management BIOS (SMBIOS) version	2.7
Desktop Management Interface (DMI) version	2.7
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Technical details
Warranty period	3 year(s)
Weight & dimensions
Depth	215 mm
Width	230 mm
Height	35 mm
Packaging
Gross weight	0,9 kg
Gross depth	265 mm
Gross width	265 mm
Gross height	54 mm
Screws included
Bundled software	Norton® Internet Security (OEM version) LAN bandwidth management software
Batteries included
