ASUS PRIME B850-PLUS-CSM AMD B850 Socket AM5 ATX

Name: ASUS PRIME B850-PLUS-CSM AMD B850 Socket AM5 ATX
Brand: Asus
SKU: 90MB1LC0-M0EAYC
Price: 216.26 EUR
Availability: InStock

Motherboards

216.26 € VAT included

In stock · 4

ASUS PRIME B850-PLUS-CSM, AMD, Socket AM5, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, DDR5-SDRAM, 256 GB, DIMM

Prime B850-PLUS-CSMASUS Prime series motherboards are expertly engineered to unleash the full potential of AMD Ryzen™ 9000 series processors. The PRIME B850-PLUS-CSM motherboard provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features. It’s designed to be Advanced AI PC-ready, offering the power and connectivity needed for demanding AI applications.

AMD Socket AM5 AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
PC ATX AMD B850 7.1 channels
DDR5-SDRAM 4 DIMM Maximum internal memory: 256 GB
HDD & SSD M.2, SATA III RAID support Number of storage drives supported: 7
BIOS type: UEFI AMI 256 Mbit
2.5 Gigabit Ethernet

Specifications

Features
Wi-Fi
Line-in
BIOS type	UEFI AMI
RAID levels	0, 1, 5, 10
Cooling type	Passive
Ethernet LAN
RAID support
Component for	PC
Microphone in
Product colour	Multicolour
Memory channels	Dual-channel
BIOS memory size	256 Mbit
Processor socket	Socket AM5
CPU fan connector
Memory slots type	DIMM
Unbuffered memory
RGB LED pin header
Top Wi-Fi standard	Not available
USB 2.0 connectors	2
USB connector type	USB Type-A, USB Type-C
12V power connector
HDMI ports quantity
Motherboard chipset	AMD B850
Thunderbolt headers
S/PDIF out connector
Audio output channels	7.1 channels
DisplayPorts quantity
Number of memory slots	4
Processor manufacturer	AMD
Supported memory types	DDR5-SDRAM
USB 2.0 ports quantity	2
Ethernet interface type	2.5 Gigabit Ethernet
Maximum internal memory	256 GB
Motherboard form factor	ATX
Number of M.2 (M) slots	3
1st M.2 largest key size	22110
Number of COM connectors
Number of HDDs supported	4
Ethernet LAN (RJ-45) ports
Motherboard chipset family	AMD
Chassis intrusion connector
Compatible processor series	AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
EPS power connector (8-pin)
Front panel audio connector
ATX Power connector (24-pin)
Number of CPU fan connectors
Number of RGB LED pin headers	3
Number of SATA III connectors	4
Supported storage drive types	HDD & SSD
Number of water pump connectors
PCI Express x16 (Gen 4.x) slots
PCI Express x16 (Gen 5.x) slots
Number of chassis fan connectors	4
Number of storage drives supported	7
Supported storage drive interfaces	M.2, SATA III
Windows operating systems supported	Windows 10 x64, Windows 11
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
1st M.2 highest PCI Express generation	5.0
Parallel processing technology support	Not supported
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
Weight & dimensions
Depth	244 mm
Width	305 mm
Height	48 mm
Packaging
Gross weight	1,24 kg
Gross depth	273 mm
Gross width	353 mm
Gross height	68 mm
