GIGABYTE B650M GAMING WIFI6E Motherboard - AMD Ryzen 9000 Series CPUs, 5+2+2 Phases VRM, up to 6400MHz DDR5 (OC), 1xPCIe 4.0 M.2, 2.5 GbE LAN, WIFI 6E, USB 3.2 Gen 1

Name: GIGABYTE B650M GAMING WIFI6E Motherboard - AMD Ryzen 9000 Series CPUs, 5+2+2 Phases VRM, up to 6400MHz DDR5 (OC), 1xPCIe 4.0 M.2, 2.5 GbE LAN, WIFI 6E, USB 3.2 Gen 1
Brand: Gigabyte
SKU: B650M GAMING WIFI6E
Price: 118.97 EUR
Availability: InStock

Motherboards

98.32 € ex VAT

In stock · 12

GIGABYTE B650M GAMING WIFI6E Motherboard - AMD Ryzen 9000 Series CPUs, 5+2+2 Phases VRM, up to 6400MHz DDR5 (OC), 1xPCIe 4.0 M.2, 2.5 GbE LAN, WIFI 6E, USB 3.2 Gen 1, AMD, Socket AM5, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, Socket AM5, DDR5-SDRAM, 128 GB

Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge

AMD Socket AM5：Supports AMD Ryzen 7000 / Ryzen 8000 / Ryzen 9000 Series Processors
Unparalleled Performance：5+2+2 Phases Digital VRM Solution
Dual Channel DDR5：2*SMD DIMMs with AMD EXPO™ & Intel® XMP Memory Module Support
SuperSpeed Storage：PCIe 4.0 x4 M.2 Connector
EZ-Latch：PCIe x16 Slot with Quick Release Design
Fast Networks：2.5GbE LAN & Wi-Fi 6E 802.11ax
Extended Connectivity：HDMI , D-sub
Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
Q-Flash Plus：Update BIOS Without Installing the CPU, Memory and Graphics Card

Specifications

Features
Battery type	CR2032
Warranty	36 mo.
Wireless
Bluetooth version	5.3
Country of origin	China
HDCP
Wi-Fi
Line-in
BIOS type	UEFI AMI
RAID levels	0, 1, 10
ACPI version	5.0
Ethernet LAN
HDMI version	2.1
RAID support
Component for	PC
Microphone in
TPM connector
Battery weight	3 g
Memory channels	Dual-channel
Wi-Fi standards	Wi-Fi 6E (802.11ax)
BIOS memory size	256 Mbit
Processor socket	Socket AM5
CPU fan connector
Clear CMOS jumper
Headphone outputs
Memory slots type	DIMM
Power source type	ATX
Unbuffered memory
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Maximum resolution	4096 x 2160 pixels
RGB LED pin header
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
USB 2.0 connectors	2
HDMI ports quantity
Motherboard chipset	AMD B650
PS/2 ports quantity
PC health monitoring	Fan, Temperature, Voltage
WiFi-AP antenna jack	2
Audio output channels	7.1 channels
Front panel connector
WLAN controller model	Realtek RTL8852CE
Number of memory slots	2
Processor manufacturer	AMD
Supported memory types	DDR5-SDRAM
USB 2.0 ports quantity	4
Ethernet interface type	2.5 Gigabit Ethernet
Maximum internal memory	128 GB
Motherboard form factor	micro ATX
Number of M.2 (M) slots
Number of battery cells
1st M.2 largest key size	2580
Number of HDDs supported	4
Ethernet LAN (RJ-45) ports
Lithium weight per battery	0.07 g
Motherboard chipset family	AMD
VGA (D-Sub) ports quantity
Compatible processor series	AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
EPS power connector (8-pin)
Front panel audio connector
Supported processor sockets	Socket AM5
ATX Power connector (24-pin)
Number of CPU fan connectors
Number of RGB LED pin headers	3
Number of SATA III connectors	4
Supported memory clock speeds	6400,6200,6000,5600,5200,4800,4400 MHz
Supported storage drive types	HDD & SSD
PCI Express x1 (Gen 3.x) slots
PCI Express x16 (Gen 4.x) slots
Maximum internal memory per slot	64 GB
Number of chassis fan connectors	2
Number of storage drives supported	5
Products per shipping (inner) case	1 pc(s)
Supported memory clock speed (max)	6400 MHz
Supported storage drive interfaces	M.2, SATA III
Windows operating systems supported	Windows 10 x64, Windows 11
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1st M.2 highest PCI Express generation	4.0
Number of EPS power connectors (8-pin)
Parallel processing technology support	Not supported
System Management BIOS (SMBIOS) version	2.7
Desktop Management Interface (DMI) version	2.7
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Technical details
Warranty period	3 year(s)
Weight & dimensions
Depth	225 mm
Width	240 mm
Height	35 mm
Packaging
Gross weight	1,21 kg
Gross depth	268 mm
Gross width	270 mm
Gross height	68 mm
Screws included
Antenna included
Bundled software	Norton® Internet Security (OEM version) LAN bandwidth management software
Batteries included
