GIGABYTE B650I AX материнская плата AMD B650 Socket AM5 Mini ITX

Name: GIGABYTE B650I AX материнская плата AMD B650 Socket AM5 Mini ITX
Brand: Gigabyte
SKU: B650I AX
Price: 159.08 EUR
Availability: InStock

Материнские платы

159.08 € НДС включён

В наличии · 17

GIGABYTE B650I AX, AMD, Socket AM5, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, Socket AM5, DDR5-SDRAM, 128 GB

GIGABYTE B650I AX. Производитель процессора: AMD, Сокет процессора: Socket AM5, Совместимые серии процессоров: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series. Поддерживаемые типы памяти: DDR5-SDRAM, Максимальная внутренняя память: 128 GB, Тип слотов памяти: DIMM. Поддерживаемые интерфейсы носителя: M.2, SATA III, Поддерживаемые типы накопителей: HDD & SSD, Уровни RAID: 0, 1. Максимальное разрешение: 4096 x 2160 пикселей. Тип Ethernet интерфейса: 2.5 Gigabit Ethernet, Контроллер LAN: Realtek RTL8125, Основной стандарт Wi-Fi: Wi-Fi 6E (802.11ax)

AMD Socket AM5 AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
ПК Mini ITX AMD B650 Realtek ALC897 7.1 канала
DDR5-SDRAM 2 DIMM Максимальная внутренняя память: 128 GB
HDD & SSD M.2, SATA III Поддержка RAID Количество поддерживаемых дисков памяти: 3
Тип BIOS: UEFI AMI 256 Mbit Версия ACPI: 5.0 Перемычка Clear CMOS
2.5 Gigabit Ethernet Wi-Fi Wi-Fi 6E (802.11ax) Bluetooth 5.3

Характеристики

Основные
Тип батареи	CR2032
Гарантия	36 мес.
Беспроводной
Версия Bluetooth	5.3
Страна происхождения	China
HDCP
Wi-Fi
Line-in
BIOS type	UEFI AMI
Audio chip	Realtek ALC897
RAID levels	0, 1
ACPI version	5.0
Ethernet LAN
HDMI version	2.1
RAID support
Component for	PC
Microphone in
Battery weight	3 g
LAN controller	Realtek RTL8125
Product colour	Brown
DirectX version	12.0
Memory channels	Dual-channel
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
BIOS memory size	256 Mbit
Processor socket	Socket AM5
CPU fan connector
Clear CMOS jumper
Headphone outputs
Memory slots type	DIMM
Power source type	ATX
Unbuffered memory
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Maximum resolution	4096 x 2160 pixels
RGB LED pin header
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
USB 2.0 connectors
12V power connector
DisplayPort version	1.4
HDMI ports quantity
Motherboard chipset	AMD B650
PC health monitoring	Fan, Temperature, Voltage
WiFi-AP antenna jack	2
Audio output channels	7.1 channels
DisplayPorts quantity
Front panel connector
WLAN controller model	Realtek RTL8852CE
Number of memory slots	2
Processor manufacturer	AMD
Supported memory types	DDR5-SDRAM
USB 2.0 ports quantity	3
Ethernet interface type	2.5 Gigabit Ethernet
Maximum internal memory	128 GB
Motherboard form factor	mini ITX
Number of M.2 (M) slots
Number of battery cells
1st M.2 largest key size	2280
Number of HDDs supported	2
Discrete graphics support
Ethernet LAN (RJ-45) ports
Lithium weight per battery	0.07 g
Motherboard chipset family	AMD
Chassis intrusion connector
Compatible processor series	AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
EPS power connector (8-pin)
Front panel audio connector
Supported processor sockets	Socket AM5
ATX Power connector (24-pin)
Number of CPU fan connectors
Number of RGB LED pin headers	2
Number of SATA III connectors	2
Supported memory clock speeds	4400,4800,5200,5600,6000,6200,6400 MHz
Supported storage drive types	HDD & SSD
Number of EATX power connectors
PCI Express x16 (Gen 4.x) slots
Maximum internal memory per slot	64 GB
Number of chassis fan connectors	2
Number of storage drives supported	3
Products per shipping (inner) case	1 pc(s)
Supported memory clock speed (max)	6400 MHz
Supported storage drive interfaces	M.2, SATA III
Windows operating systems supported	Windows 10 x64, Windows 11 x64
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
1st M.2 highest PCI Express generation	4.0
Parallel processing technology support	Not supported
System Management BIOS (SMBIOS) version	2.7
Desktop Management Interface (DMI) version	2.7
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
Технические данные
Warranty period	3 year(s)
Вес и размеры
Depth	170 mm
Width	170 mm
Height	35 mm
Упаковка
Вес брутто	0,879 кг
Глубина брутто	180 мм
Ширина брутто	222 мм
Высота брутто	65 мм
Screws included
Antenna included
Bundled software	Norton® Internet Security (OEM version) LAN bandwidth management software
Batteries included
