GIGABYTE B650I AX mātes plate AMD B650 AM5 pieslēgvieta mini ITX

Name: GIGABYTE B650I AX mātes plate AMD B650 AM5 pieslēgvieta mini ITX
Brand: Gigabyte
SKU: B650I AX
Price: 159.08 EUR
Availability: InStock

Mātesplates (Motherboard)

131.47 € bez PVN

Noliktavā · 17

GIGABYTE B650I AX, AMD, AM5 pieslēgvieta, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, AM5 pieslēgvieta, DDR5-SDRAM, 128 GB

GIGABYTE B650I AX. Procesora ražotājs: AMD, Procesora ligzda: AM5 pieslēgvieta, Savietojami procesori: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series. Atbalstītās atmiņas veidi: DDR5-SDRAM, Maksimālā iekšējā atmiņa: 128 GB, Atmiņas slotu tips: DIMM. Atbalstītie glabāšanas diska interfeisi: M.2, SATA III, Atbalstītie atmiņas disku veidi: HDD & SSD, RAID līmeņi: 0, 1. Maksimālā izšķirtspēja: 4096 x 2160 pikseļi. Ethernet interfeisa tips: 2.5 Gigabit Ethernet, LAN kontrollers: Realtek RTL8125, Wi-Fi standarts: Wi-Fi 6E (802.11ax)

AMD AM5 pieslēgvieta AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
PC (dators) mini ITX AMD B650 Realtek ALC897 7.1 kanāli
DDR5-SDRAM 2 DIMM Maksimālā iekšējā atmiņa: 128 GB
HDD & SSD M.2, SATA III Atbalsta RAID Atbalstītais uzglabāšanas diskdziņu skaits: 3
BIOS tips: UEFI AMI 256 Mbit ACPI versija: 5.0 Nodzēst CMOS savienotājvads
2.5 Gigabit Ethernet Wi-Fi Wi-Fi 6E (802.11ax) Bluetooth 5.3

Specifikācija

Galvenie parametri
Baterijas tips	CR2032
Garantija	36 mēn.
Bezvadu
Bluetooth versija	5.3
Izcelsmes valsts	China
HDCP
Wi-Fi
Line-in
BIOS type	UEFI AMI
Audio chip	Realtek ALC897
RAID levels	0, 1
ACPI version	5.0
Ethernet LAN
HDMI version	2.1
RAID support
Component for	PC
Microphone in
Battery weight	3 g
LAN controller	Realtek RTL8125
Product colour	Brown
DirectX version	12.0
Memory channels	Dual-channel
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
BIOS memory size	256 Mbit
Processor socket	Socket AM5
CPU fan connector
Clear CMOS jumper
Headphone outputs
Memory slots type	DIMM
Power source type	ATX
Unbuffered memory
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Maximum resolution	4096 x 2160 pixels
RGB LED pin header
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
USB 2.0 connectors
12V power connector
DisplayPort version	1.4
HDMI ports quantity
Motherboard chipset	AMD B650
PC health monitoring	Fan, Temperature, Voltage
WiFi-AP antenna jack	2
Audio output channels	7.1 channels
DisplayPorts quantity
Front panel connector
WLAN controller model	Realtek RTL8852CE
Number of memory slots	2
Processor manufacturer	AMD
Supported memory types	DDR5-SDRAM
USB 2.0 ports quantity	3
Ethernet interface type	2.5 Gigabit Ethernet
Maximum internal memory	128 GB
Motherboard form factor	mini ITX
Number of M.2 (M) slots
Number of battery cells
1st M.2 largest key size	2280
Number of HDDs supported	2
Discrete graphics support
Ethernet LAN (RJ-45) ports
Lithium weight per battery	0.07 g
Motherboard chipset family	AMD
Chassis intrusion connector
Compatible processor series	AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
EPS power connector (8-pin)
Front panel audio connector
Supported processor sockets	Socket AM5
ATX Power connector (24-pin)
Number of CPU fan connectors
Number of RGB LED pin headers	2
Number of SATA III connectors	2
Supported memory clock speeds	4400,4800,5200,5600,6000,6200,6400 MHz
Supported storage drive types	HDD & SSD
Number of EATX power connectors
PCI Express x16 (Gen 4.x) slots
Maximum internal memory per slot	64 GB
Number of chassis fan connectors	2
Number of storage drives supported	3
Products per shipping (inner) case	1 pc(s)
Supported memory clock speed (max)	6400 MHz
Supported storage drive interfaces	M.2, SATA III
Windows operating systems supported	Windows 10 x64, Windows 11 x64
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
1st M.2 highest PCI Express generation	4.0
Parallel processing technology support	Not supported
System Management BIOS (SMBIOS) version	2.7
Desktop Management Interface (DMI) version	2.7
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
Tehniskie dati
Warranty period	3 year(s)
Svars un izmēri
Depth	170 mm
Width	170 mm
Height	35 mm
Iepakojums
Bruto svars	0,879 kg
Bruto dziļums	180 mm
Bruto platums	222 mm
Bruto augstums	65 mm
Screws included
Antenna included
Bundled software	Norton® Internet Security (OEM version) LAN bandwidth management software
Batteries included
