Asus

ASUS PRIME B850-PLUS-CSM AMD B850 AM5 pieslēgvieta ATX

Mātesplates (Motherboard)

216.26 € PVN iekļauts

Noliktavā · 4

ASUS PRIME B850-PLUS-CSM, AMD, AM5 pieslēgvieta, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, DDR5-SDRAM, 256 GB, DIMM

ASUS PRIME B850-PLUS-CSM. Procesora ražotājs: AMD, Procesora ligzda: AM5 pieslēgvieta, Savietojami procesori: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series. Atbalstītās atmiņas veidi: DDR5-SDRAM, Maksimālā iekšējā atmiņa: 256 GB, Atmiņas slotu tips: DIMM. Atbalstītie glabāšanas diska interfeisi: M.2, SATA III, Atbalstītie atmiņas disku veidi: HDD & SSD, RAID līmeņi: 0, 1, 5, 10. USB savienotājs: USB Type-A, USB Veids-C. Ethernet interfeisa tips: 2.5 Gigabit Ethernet

  • AMD AM5 pieslēgvieta AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
  • PC (dators) ATX AMD B850 7.1 kanāli
  • DDR5-SDRAM 4 DIMM Maksimālā iekšējā atmiņa: 256 GB
  • HDD & SSD M.2, SATA III Atbalsta RAID Atbalstītais uzglabāšanas diskdziņu skaits: 7
  • BIOS tips: UEFI AMI 256 Mbit
  • 2.5 Gigabit Ethernet

Specifikācija

Galvenie parametri
Wi-Fi
Line-in
BIOS type UEFI AMI
RAID levels 0, 1, 5, 10
Cooling type Passive
Ethernet LAN
RAID support
Component for PC
Microphone in
Product colour Multicolour
Memory channels Dual-channel
BIOS memory size 256 Mbit
Processor socket Socket AM5
CPU fan connector
Memory slots type DIMM
Unbuffered memory
RGB LED pin header
Top Wi-Fi standard Not available
USB 2.0 connectors 2
USB connector type USB Type-A, USB Type-C
12V power connector
HDMI ports quantity
Motherboard chipset AMD B850
Thunderbolt headers
S/PDIF out connector
Audio output channels 7.1 channels
DisplayPorts quantity
Number of memory slots 4
Processor manufacturer AMD
Supported memory types DDR5-SDRAM
USB 2.0 ports quantity 2
Ethernet interface type 2.5 Gigabit Ethernet
Maximum internal memory 256 GB
Motherboard form factor ATX
Number of M.2 (M) slots 3
1st M.2 largest key size 22110
Number of COM connectors
Number of HDDs supported 4
Ethernet LAN (RJ-45) ports
Motherboard chipset family AMD
Chassis intrusion connector
Compatible processor series AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
EPS power connector (8-pin)
Front panel audio connector
ATX Power connector (24-pin)
Number of CPU fan connectors
Number of RGB LED pin headers 3
Number of SATA III connectors 4
Supported storage drive types HDD & SSD
Number of water pump connectors
PCI Express x16 (Gen 4.x) slots
PCI Express x16 (Gen 5.x) slots
Number of chassis fan connectors 4
Number of storage drives supported 7
Supported storage drive interfaces M.2, SATA III
Windows operating systems supported Windows 10 x64, Windows 11
USB 3.2 Gen 1 (3.1 Gen 1) connectors 2
1st M.2 highest PCI Express generation 5.0
Parallel processing technology support Not supported
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
Svars un izmēri
Depth 244 mm
Width 305 mm
Height 48 mm
Iepakojums
Bruto svars 1,24 kg
Bruto dziļums 273 mm
Bruto platums 353 mm
Bruto augstums 68 mm
