MSI MAG A750GL PCIE5 barošanas avotu vienība 750 W 20+4 pin ATX ATX Melns

Name: MSI MAG A750GL PCIE5 barošanas avotu vienība 750 W 20+4 pin ATX ATX Melns
Brand: MSI
SKU: MAG A750GL PCIE5
Price: 121.65 EUR
Availability: InStock

Barošanas bloki (PSU)

100.54 € bez PVN

Noliktavā · 8

MSI MAG A750GL PCIE5, 750 W, 100 - 240 V, 47 - 63 Hz, 8 A, 4 A, Aktīvs

MSI MAG A750GL PCIE5. Kopējā jauda: 750 W, Maiņstrāvas ievades spriegums: 100 - 240 V, Maiņstrāvas ievades frekvence: 47 - 63 Hz. Mātesplates strāvas konektors: 20+4 pin ATX, Mātesplates barošanas vada garums: 45 cm, Kabeļu tips: Pilnībā modulāra uzbūve. Mērķis, rezultāts: PC (dators), Strāvas padeves bloka (PSU) formas faktors: ATX, 80 PLUS sertifikācija: 80 PLUS Gold. Produkta krāsa: Melns, Dzesēšanas tips: Aktīvs, Ventilatora diametrs: 12 cm. Platums: 150 mm, Dziļums: 140 mm, Augstums: 86 mm

750 W 100 - 240 V 47 - 63 Hz
Mātesplates strāvas konektors: 20+4 pin ATX
PC (dators) ATX 80 PLUS Gold
Aktīvs 12 cm
Melns

Specifikācija

Galvenie parametri
Garantija	24 mēn.
Maiņstrāvas frekvence	47 - 63 Hz
Maiņstrāvas spriegums	100 - 240 V
Purpose	PC
Efficiency	90%
ATX version	3.1
Total power	750 W
Cabling type	Fully-Modular
Cooling type	Active
Fan diameter	12 cm
Illumination
On/off switch
Number of fans	1 fan(s)
Product colour	Black
Combined power (+5V)	110 W
80 PLUS certification	80 PLUS Gold
Combined power (+12V)	744 W
Combined power (-12V)	3.6 W
PCI Express connector
Combined power (+3.3V)	110 W
Combined power (+5Vsb)	12.5 W
Max output current (+5V)	20 A
Max output current (+12V)	62 A
Max output current (-12V)	0.3 A
Power protection features	Over current, Over power, Over voltage, Overheating, Short circuit
Max output current (+3.3V)	20 A
Max output current (+5Vsb)	2.5 A
EPS power connector (8-pin)
Motherboard power connector	20+4 pin ATX
ATX Power connector (24-pin)
CPU power connector (4+4 pin)
EPS power connector (4+4 pin)
Maximum input current (@110V)	8 A
Maximum input current (@220V)	4 A
ATX power connector (20+4 pin)
Motherboard power cable length	45 cm
Number of SATA power connectors	8
Power Factor Correction (PFC) type	Active
Power supply unit (PSU) form factor	ATX
PCI Express power connectors (6+2 pin)	3
Peripheral (Molex) power connectors (4-pin)	4
Svars un izmēri
Depth	140 mm
Width	150 mm
Height	86 mm
Iepakojums
Iepakojuma tips	Box
