Gigabyte

GIGABYTE GP-UD850GM PG5 barošanas avotu vienība 850 W 20+4 pin ATX ATX Melns

Barošanas bloki (PSU)

109.15 € PVN iekļauts

Noliktavā · 24

GIGABYTE GP-UD850GM PG5, 850 W, 100 - 240 V, 50 - 60 Hz, 12 - 6 A, 6 A, 12 A

GIGABYTE GP-UD850GM PG5. Kopējā jauda: 850 W, Maiņstrāvas ievades spriegums: 100 - 240 V, Maiņstrāvas ievades frekvence: 50 - 60 Hz. Mātesplates strāvas konektors: 20+4 pin ATX, Mātesplates barošanas vada garums: 61 cm, SATA strāvas kabeļa garums: 150,600 mm. Mērķis, rezultāts: PC (dators), Strāvas padeves bloka (PSU) formas faktors: ATX, 80 PLUS sertifikācija: 80 PLUS Gold. Produkta krāsa: Melns, Dzesēšanas tips: Aktīvs, Ventilatora diametrs: 12 cm. Pievienoti kabeļi: Centrālais procesors, PATA, Peripheral (Molex), SATA

  • 850 W 100 - 240 V 50 - 60 Hz
  • Mātesplates strāvas konektors: 20+4 pin ATX
  • PC (dators) ATX 80 PLUS Gold
  • Aktīvs 12 cm
  • Melns

Specifikācija

Galvenie parametri
Garantija 60 mēn.
Trokšņa līmenis 40 dB
Maiņstrāvas frekvence 50 - 60 Hz
Maiņstrāvas spriegums 100 - 240 V
Purpose PC
Hold time 16 ms
Efficiency 90%
Total power 850 W
Cabling type Fully-Modular
Cooling type Active
Fan diameter 12 cm
Fan location Top
Illumination
Input current 12 - 6 A
Number of fans 1 fan(s)
Product colour Black
Warranty period 5 year(s)
Combined power (+5V) 105 W
80 PLUS certification 80 PLUS Gold
Combined power (+12V) 850 W
Combined power (-12V) 3.6 W
PCI Express connector
Combined power (+3.3V) 105 W
Combined power (+5Vsb) 15 W
Compliance certificates CCC, CE, Federal Communications Commission (FCC), RoHS
SATA power cable length 150,600 mm
Max output current (+5V) 20 A
Max output current (+12V) 70.8 A
Max output current (-12V) 0.3 A
Power protection features Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Max output current (+3.3V) 20 A
Max output current (+5Vsb) 3 A
Motherboard power connector 20+4 pin ATX
CPU power connector (4+4 pin)
Maximum input current (@110V) 6 A
Maximum input current (@220V) 12 A
ATX power connector (20+4 pin)
Motherboard power cable length 61 cm
PCI Express power cable length 70 cm
Number of PATA power connectors 3
Number of SATA power connectors 8
Mean time between failures (MTBF) 100000 h
Power Factor Correction (PFC) type Active
Power supply unit (PSU) form factor ATX
PCI Express power connectors (16-pin)
Peripheral (Molex) power cable length 200,600 mm
PCI Express power connectors (6+2 pin) 4
Peripheral (Molex) power connectors (4-pin) 2
Svars un izmēri
Depth 140 mm
Width 150 mm
Height 85 mm
Iepakojums
Iepakojuma tips Box
Cables included CPU, PATA, Peripheral (Molex), SATA
Cable tie(s) included
