TP-Link Omada 10-Port Gigabit Smart Switch with 8-Port PoE+

Name: TP-Link Omada 10-Port Gigabit Smart Switch with 8-Port PoE+
Brand: TP-Link
SKU: TL-SG2210MP
Price: 178.49 EUR
Availability: InStock

Switches and power supplies

178.49 € VAT included

In stock · 18

TP-Link Omada 10-Port Gigabit Smart Switch with 8-Port PoE+, Managed, L2/L2+, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U

TP-Link’s brand new Omada smart switches provide huge upgrade comparing with previous versions. The switches can be managed by Omada SDN Controller, which provides professional and reliable one-step solutions. Integrated L2 and L2+ features such as 802.1Q VLAN, QoS, IGMP Snooping and static routing provide cost-effective networking solutions for small and medium-sized businesses without sacrificing enhanced usability and strong performance.

8× Gigabit 802.3af/at PoE+ ports and 2× Gigabit SFP slots
150 W total PoE budget with up to 30 W PoE output per port*
Centralized cloud management via the web or the Omada app†
Standalone management via web, CLI, SNMP, and RMON
Static Routing helps route internal traffic for higher efficiency
VLAN, ACL, QoS, and IGMP Snooping
Durable metal casing and desktop/rack mounting design

Specifications

Features
Chassis type	1U
Switch type	Managed
AC input frequency	50/60 Hz
AC input voltage	100 - 240 V
10G support
MIB support	RFC2925, RFC2618, RFC2620, RFC2021, RFC2819, RFC2674, RFC1213, RFC2233, RFC1643, RFC1493
Jumbo frames	9000
Power source	AC
Switch layer	L2/L2+
VLAN support
Certification	CE, FCC, RoHS
Cloud-managed
DHCP features	DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping
IGMP snooping
Rack mounting
Rate limiting
ARP inspection
Number of fans	1 fan(s)
Port mirroring
Product colour	Black
Forwarding rate	14.9 Mpps
Number of VLANs	4000
SSH/SSL support
Heat dissipation	594.46 BTU/h
Link aggregation
Number of queues	8
System event log
MAC address table	8000 entries
Multicast support
Switching capacity	20 Gbit/s
IP-MAC-Port binding
Security algorithms	EAP-LEAP, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, SNMP, SNMPv2, SNMPv3, SSH, SSH-2, SSL/TLS
Flow control support
Jumbo frames support
Management protocols	SNMPv1/v2c/v3, SNTP
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Packet buffer memory	4.1 MB
Virtual LAN features	MAC address-based VLAN, Multicast VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
Web-based management
Power supply included
Spanning tree protocol
Broadcast storm control
Power consumption (max)	173.9 W
Access Control List (ACL)
BPDU filtering/protection
Power over Ethernet (PoE)
SFP module slots quantity	2
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Queue scheduling algorithms	SP, Weighted Round Robin (WRR)
Storage relative humidity (H-H)	5 - 90%
Quality of Service (QoS) support
Fiber ethernet cabling technology	100BASE-FX, 1000BASE-X
Operating relative humidity (H-H)	10 - 90%
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Configuring Location Settings (CLI)
Total Power over Ethernet (PoE) budget	150 W
Gigabit Ethernet (copper) ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Power over Ethernet plus (PoE+) ports quantity	8
Weight & dimensions
Depth	180 mm
Width	294 mm
Height	44 mm
