ASUS PROART B850-CREATOR WIFI NEO AMD B850 Socket AM5 ATX

Name: ASUS PROART B850-CREATOR WIFI NEO AMD B850 Socket AM5 ATX
Brand: Asus
SKU: 90MB1P60-M0EAY0
Price: 293.99 EUR
Availability: InStock

Motherboards

293.99 € VAT included

In stock · 5

ASUS PROART B850-CREATOR WIFI NEO, AMD, Socket AM5, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, Socket AM5, DDR5-SDRAM, 256 GB

The ProArt B850-Creator WiFi Neo is designed to empower creators at every level, delivering optimized performance for the latest AMD Ryzen™ 9000, 8000, and 7000 Series processors, as well as AMD EPYC™ 4005 Series CPUs. Featuring a robust 14+2+1 power stage design, DDR5 support, PCIe® 5.0 expansion, and ultrafast connectivity—including dual 5G Ethernet and WiFi 7—it provides a reliable foundation for demanding creative workloads.With a refined aesthetic that reflects a professional and elegant design philosophy, the motherboard showcases layered black tones accented with metallic gold details. This platform seamlessly combines performance, connectivity, and design, delivering the power required for today's advanced AI PC applications.

AMD Socket AM5 AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
PC ATX AMD B850 Realtek ALC1220P 7.1 channels
DDR5-SDRAM 4 DIMM Maximum internal memory: 256 GB
HDD & SSD M.2, SATA III RAID support Number of storage drives supported: 7
BIOS type: UEFI AMI 512 Mbit
5 Gigabit Ethernet Wi-Fi Wi-Fi 7 (802.11be) Bluetooth

Specifications

Features
Warranty	36 mo.
Wireless
Wi-Fi
Line-in
BIOS type	UEFI AMI
Audio chip	Realtek ALC1220P
RAID levels	0, 1, 5, 10
Cooling type	Passive
Ethernet LAN
HDMI version	2.1
RAID support
Component for	PC
Microphone in
TPM connector
Product colour	Black
Memory channels	Dual-channel
Wi-Fi standards	Wi-Fi 7 (802.11be)
BIOS memory size	512 Mbit
Processor socket	Socket AM5
CPU fan connector
Headphone outputs
Memory slots type	DIMM
Power source type	ATX
Unbuffered memory
Maximum resolution	7680 x 4320 pixels
RGB LED pin header
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
USB 2.0 connectors	2
DisplayPort version	1.4
HDMI ports quantity
Motherboard chipset	AMD B850
Thunderbolt headers
WiFi-AP antenna jack	2
Audio output channels	7.1 channels
BIOS flashback button
DisplayPorts quantity
Front panel connector
WLAN controller model	Realtek RTL8922AE
Number of memory slots	4
On-board graphics card
Processor manufacturer	AMD
Supported memory types	DDR5-SDRAM
USB 2.0 ports quantity	4
Ethernet interface type	5 Gigabit Ethernet
Maximum internal memory	256 GB
Motherboard form factor	ATX
Number of M.2 (M) slots	3
1st M.2 largest key size	2280
2nd M.2 largest key size	2280
3rd M.2 largest key size	2280
Number of COM connectors
Number of HDDs supported	4
Ethernet LAN (RJ-45) ports	2
Motherboard chipset family	AMD
Chassis intrusion connector
Compatible processor series	AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
EPS power connector (8-pin)
Front panel audio connector
Supported processor sockets	Socket AM5
ATX Power connector (24-pin)
Number of CPU fan connectors	2
Number of RGB LED pin headers	3
Number of SATA III connectors	4
Supported storage drive types	HDD & SSD
PCI Express x4 (Gen 1.x) slots
Number of water pump connectors
PCI Express x16 (Gen 4.x) slots	2
PCI Express x16 (Gen 5.x) slots	2
Maximum internal memory per slot	64 GB
Number of chassis fan connectors	4
Number of storage drives supported	7
Supported memory clock speed (max)	9000 MHz
Supported storage drive interfaces	M.2, SATA III
Windows operating systems supported	Windows 11
Number of temperature sensor headers
USB 3.2 Gen 1 (3.1 Gen 1) connectors
USB 3.2 Gen 2 (3.1 Gen 2) connectors
1st M.2 highest PCI Express generation	5.0
2nd M.2 highest PCI Express generation	5.0
3rd M.2 highest PCI Express generation	4.0
Number of EPS power connectors (8-pin)	2
Parallel processing technology support	Not supported
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
Weight & dimensions
Depth	244 mm
Width	305 mm
Height	48 mm
Other
Quick installation guide
Packaging
Gross weight	2,14 kg
Gross depth	273 mm
Gross width	353 mm
Gross height	68 mm
Cables included	SATA
Screws included
Antenna included
