GIGABYTE B840M D2H Motherboard - AMD Ryzen 9000 CPUs, 5+2+2 Phases VRM, up to 7600MHz DDR5, 1xPCIe 4.0 + 1xPCIe 3.0 M.2, 2.5GbE LAN, USB 3.2 Gen 1

Name: GIGABYTE B840M D2H Motherboard - AMD Ryzen 9000 CPUs, 5+2+2 Phases VRM, up to 7600MHz DDR5, 1xPCIe 4.0 + 1xPCIe 3.0 M.2, 2.5GbE LAN, USB 3.2 Gen 1
Brand: Gigabyte
SKU: B840M D2H
Price: 103.22 EUR
Availability: InStock

Motherboards

103.22 € VAT included

In stock · 23

GIGABYTE B840M D2H Motherboard - AMD Ryzen 9000 CPUs, 5+2+2 Phases VRM, up to 7600MHz DDR5, 1xPCIe 4.0 + 1xPCIe 3.0 M.2, 2.5GbE LAN, USB 3.2 Gen 1, AMD, Socket AM5, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, Socket AM5, DDR5-SDRAM, 128 GB

Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge

X3D Turbo Mode to unleash new era gaming performance
AMD Socket AM5 : Supports AMD Ryzen 9000 / 8000 / 7000 Series Processors
Digital 5+2+2 phases VRM solution
Dual Channel DDR5 : 2*DIMMs with AMD EXPO Memory Module Support
EZ-Latch : PCIe x16 Slot with Quick Release Design
Friendly UI : Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW
Ultra-Fast Storage : 2*M.2 slots, including 1* PCIe 4.0 x4
Fast Networking : 2.5GbE LAN

Specifications

Features
Battery type	CR2032
Warranty	36 mo.
HDCP
Wi-Fi
Line-in
BIOS type	UEFI AMI
Audio chip	Realtek ALC897
RAID levels	0, 1, 10
ACPI version	5.0
Cooling type	Passive
Ethernet LAN
HDMI version	2.1
RAID support
Component for	PC
Microphone in
TPM connector
Battery weight	3 g
LAN controller	Realtek RTL8125
Product colour	Dark brown
DirectX version	12.0
Memory channels	Dual-channel
BIOS memory size	256 Mbit
Processor socket	Socket AM5
CPU fan connector
Clear CMOS jumper
Headphone outputs
Memory slots type	DIMM
Power source type	ATX
Unbuffered memory
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Maximum resolution	4096 x 2160 pixels
RGB LED pin header
USB 2.0 connectors	2
HDMI ports quantity
Motherboard chipset	AMD B840
PS/2 ports quantity
PC health monitoring	Fan, Temperature, Voltage, Water cooling
Audio output channels	7.1 channels
Front panel connector
Number of memory slots	2
Processor manufacturer	AMD
Supported memory types	DDR5-SDRAM
USB 2.0 ports quantity	4
Ethernet interface type	2.5 Gigabit Ethernet
Maximum internal memory	128 GB
Motherboard form factor	micro ATX
Number of M.2 (M) slots	2
Number of battery cells
1st M.2 largest key size	2580
2nd M.2 largest key size	2280
Number of HDDs supported	4
Ethernet LAN (RJ-45) ports
Lithium weight per battery	0.07 g
Motherboard chipset family	AMD
Compatible processor series	AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
EPS power connector (8-pin)
Front panel audio connector
Supported processor sockets	Socket AM5
ATX Power connector (24-pin)
Number of CPU fan connectors	2
Number of RGB LED pin headers	3
Number of SATA III connectors	4
Supported memory clock speeds	7600,7200,7000,6800,6666,6600,6400,6200,6000,5600,5200,4800,4400 MHz
Supported storage drive types	HDD & SSD
Number of water pump connectors
PCI Express x16 (Gen 3.x) slots
PCI Express x16 (Gen 4.x) slots
Maximum internal memory per slot	64 GB
Number of chassis fan connectors
Number of storage drives supported	6
Products per shipping (inner) case	1 pc(s)
Supported memory clock speed (max)	7600 MHz
Supported storage drive interfaces	M.2, PCI Express 4.0, SATA III
Windows operating systems supported	Windows 10 x64, Windows 11 x64
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1st M.2 highest PCI Express generation	4.0
2nd M.2 highest PCI Express generation	3.0
Number of EPS power connectors (8-pin)
Parallel processing technology support	Not supported
System Management BIOS (SMBIOS) version	2.7
Desktop Management Interface (DMI) version	2.7
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Technical details
Warranty period	3 year(s)
Weight & dimensions
Depth	244 mm
Width	244 mm
Height	35 mm
Packaging
Gross weight	1,03 kg
Gross depth	265 mm
Gross width	265 mm
Gross height	54 mm
Screws included
Bundled software	Norton® Internet Security (OEM version) LAN bandwidth management software
Batteries included
