GIGABYTE GAMING 750GM PG5 Power Supply Unit - PCIe 5.1, 80 PLUS Gold, Fully Modular Design, 135mm Fan, ATX 3.1 compatible, EU Plug

Name: GIGABYTE GAMING 750GM PG5 Power Supply Unit - PCIe 5.1, 80 PLUS Gold, Fully Modular Design, 135mm Fan, ATX 3.1 compatible, EU Plug
Brand: Gigabyte
SKU: GP-GME750GM PG5
Price: 114.60 EUR
Availability: InStock

Power supply units (PSU)

114.60 € VAT included

In stock · 15

GIGABYTE GAMING 750GM PG5 Power Supply Unit - PCIe 5.1, 80 PLUS Gold, Fully Modular Design, 135mm Fan, ATX 3.1 compatible, EU Plug, 750 W, 100 - 240 V, 50/60 Hz, 10 A, Active, 120 W

Ensure reliable and efficient power delivery with GIGABYTE power supplies. Designed for peak performance and durability, our PSUs offer stable and consistent energy to power your high-performance systems. With advanced protections and high-quality components, GIGABYTE power supplies provide the confidence you need for seamless, uninterrupted computing experiences.

80 PLUS Gold certified
Cybenetics ETA Platinum & LAMBDA A+ certified
T-Guard Active GPU Protection
135mm Smart Fluid Dynamic Bearing (FDB) Fan
HybridCool Smart Fan Control
100% Japanese capacitors
Powerful single +12V rail
OVP/OPP/SCP/UVP/OCP/OTP/NLO/SIP protection
10-year warranty (Subject to region)

Specifications

Features
Warranty	120 mo.
AC input frequency	50/60 Hz
AC input voltage	100 - 240 V
Purpose	PC
Hold time	17 ms
Efficiency	90%
ATX version	3.1
Total power	750 W
Cabling type	Fully-Modular
Cooling type	Active
Fan diameter	13.5 cm
Fan location	Top
Power factor	0.9
Input current	10 A
On/off switch
Number of fans	1 fan(s)
Product colour	Black
Warranty period	10 year(s)
Bearing technology	FDB
Combined power (+5V)	120 W
80 PLUS certification	80 PLUS Gold
Combined power (+12V)	750 W
Combined power (-12V)	3.6 W
PCI Express connector
Combined power (+3.3V)	120 W
Combined power (+5Vsb)	15 W
Max output current (+5V)	20 A
Number of EPS connectors	2
Max output current (+12V)	62.5 A
Max output current (-12V)	0.3 A
Power protection features	Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage, Surge & inrush protection (SIP), No load operation
Max output current (+3.3V)	20 A
Max output current (+5Vsb)	3 A
Motherboard power connector	20+4 pin ATX
Number of SATA power cables	2
CPU power connector (4+4 pin)
EPS power connector (4+4 pin)
Power Good signal delay range	100 - 150 ms
ATX power connector (20+4 pin)
Motherboard power cable length	61 cm
Number of SATA power connectors	8
Mean time between failures (MTBF)	100000 h
Power Factor Correction (PFC) type	Active
Power supply unit (PSU) form factor	ATX
PCI Express power connectors (16-pin)
PCI Express power connectors (6+2 pin)	4
Peripheral (Molex) power connectors (4-pin)	4
Weight & dimensions
Depth	150 mm
Width	150 mm
Height	86 mm
Packaging
Gross weight	3,1 kg
Gross depth	184 mm
Gross width	302 mm
Gross height	129 mm
Package type	Box
