Chieftec EON power supply unit 700 W 20+4 pin ATX ATX Black

Name: Chieftec EON power supply unit 700 W 20+4 pin ATX ATX Black
Brand: Chieftec
SKU: ZPU-700S
Price: 51.61 EUR
Availability: InStock

Power supply units (PSU)

42.65 € ex VAT

In stock · 3

Chieftec EON , 700 W, 200 - 240 V, 50 Hz, 5.5 A, 5.5 A, Active

The EON Series offers high quality and 80 PLUS® 230V EU efficiency at highlycompetitive pricing, equipped with silent 120mm fans.The power supplies are fully built from steel, coated in elegant black, andequipped with extra-long native cables. The EON Series runs quietly and providesits power with all essential protection and safety features.

700 W 200 - 240 V 50 Hz
Motherboard power connector: 20+4 pin ATX
PC/Server ATX 80 PLUS
12 cm
Black

Specifications

Features
Warranty	24 mo.
AC input frequency	50 Hz
AC input voltage	200 - 240 V
Purpose	PC/Server
ATX version	2.3
Total power	700 W
Cabling type	Non-Modular
Fan diameter	12 cm
Power factor	0.9
Input current	5.5 A
On/off switch
Product colour	Black
Warranty period	2 year(s)
80 PLUS certification	80 PLUS
Combined power (-12V)	4.8 W
SATA power cable length	450,600,750 mm
Max output current (+5V)	20 A
Max output current (-12V)	0.4 A
Power protection features	Surge and inrush, Surge protection, Short circuit
Max output current (+12V1)	53 A
Max output current (+3.3V)	20 A
Max output current (+5Vsb)	2.5 A
Motherboard power connector	20+4 pin ATX
CPU power connector (4+4 pin)
EPS power connector (4+4 pin)
Maximum input current (@220V)	5.5 A
ATX power connector (20+4 pin)
Motherboard power cable length	65 cm
Number of SATA power connectors	4
Power Factor Correction (PFC) type	Active
Supported motherboard form factors	ATX
Power supply unit (PSU) form factor	ATX
Peripheral (Molex) power cable length	450,600,750 mm
PCI Express power connectors (6+2 pin)	2
Weight & dimensions
Depth	140 mm
Width	150 mm
Height	86 mm
