GIGABYTE B760M D3HP WIFI6 материнская плата Intel B760 Express LGA 1700 Микро ATX

Name: GIGABYTE B760M D3HP WIFI6 материнская плата Intel B760 Express LGA 1700 Микро ATX
Brand: Gigabyte
SKU: B760M D3HP WIFI6
Price: 105.48 EUR
Availability: InStock

Материнские платы

87.17 € без НДС

В наличии · 10

GIGABYTE B760M D3HP WIFI6, Intel, LGA 1700, Процессор Intel® Celeron®, Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core..., LGA 1700, DDR5-SDRAM, 192 GB

GIGABYTE B760M D3HP WIFI6. Производитель процессора: Intel, Сокет процессора: LGA 1700, Совместимые серии процессоров: Процессор Intel® Celeron®, Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core.... Поддерживаемые типы памяти: DDR5-SDRAM, Максимальная внутренняя память: 192 GB, Тип слотов памяти: DIMM. Поддерживаемые интерфейсы носителя: M.2, PCI Express 4.0, SATA III, Поддерживаемые типы накопителей: HDD & SSD, Уровни RAID: 0, 1, 5, 10. Максимальное разрешение: 4096 x 2304 пикселей. Тип Ethernet интерфейса: Гигабитный Ethernet, Контроллер LAN: Realtek RTL8111H, Основной стандарт Wi-Fi: Wi-Fi 6 (802.11ax)

Intel LGA 1700 Процессор Intel® Celeron®, Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel Core i5 12th Gen, Intel Core i5 13th Gen, Intel Core i5 14th Gen, Intel Core i7 12th Gen, Intel Core i7 13th Gen, Intel Core i7 14th Gen, Intel Core i9 12th Gen, Intel Core i9 13th Gen, Intel Core i9 14th Gen, Intel® Pentium® Gold
ПК Микро ATX Intel B760 Express Realtek ALC897 7.1 канала
DDR5-SDRAM 4 DIMM Максимальная внутренняя память: 192 GB
HDD & SSD M.2, PCI Express 4.0, SATA III Поддержка RAID Количество поддерживаемых дисков памяти: 6
Тип BIOS: UEFI AMI 128 Mbit Версия ACPI: 5.0 Перемычка Clear CMOS
Гигабитный Ethernet Wi-Fi Wi-Fi 6 (802.11ax) Bluetooth 5.3

Характеристики

Основные
Тип батареи	CR2032
Гарантия	36 мес.
Беспроводной
Версия Bluetooth	5.3
HDCP
Wi-Fi
Line-in
BIOS type	UEFI AMI
Audio chip	Realtek ALC897
RAID levels	0, 1, 5, 10
ACPI version	5.0
Cooling type	Passive
Ethernet LAN
HDMI version	2.1
RAID support
Component for	PC
Microphone in
TPM connector
Battery weight	3 g
LAN controller	Realtek RTL8111H
Product colour	Dark brown
DirectX version	12.0
Memory channels	Dual-channel
Wi-Fi standards	Wi-Fi 6 (802.11ax)
BIOS memory size	128 Mbit
Processor socket	LGA 1700
CPU fan connector
Clear CMOS jumper
Headphone outputs
Memory slots type	DIMM
Power source type	ATX
Unbuffered memory
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Maximum resolution	4096 x 2304 pixels
Parallel connector
RGB LED pin header
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
USB 2.0 connectors	2
12V power connector
DisplayPort version	1.2
HDMI ports quantity
Motherboard chipset	Intel B760 Express
PS/2 ports quantity
Serial port headers
PC health monitoring	Fan, Temperature, Voltage, Water cooling
S/PDIF out connector
WiFi-AP antenna jack	2
Audio output channels	7.1 channels
DisplayPorts quantity
Front panel connector
WLAN controller model	Realtek RTL8851BE
Number of memory slots	4
Processor manufacturer	Intel
Supported memory types	DDR5-SDRAM
USB 2.0 ports quantity	2
Ethernet interface type	Gigabit Ethernet
Maximum internal memory	192 GB
Motherboard form factor	micro ATX
Number of M.2 (M) slots	2
Number of battery cells
1st M.2 largest key size	2280
2nd M.2 largest key size	2280
Number of HDDs supported	4
Ethernet LAN (RJ-45) ports
Lithium weight per battery	0.07 g
Motherboard chipset family	Intel
VGA (D-Sub) ports quantity
Compatible processor series	Intel® Celeron®, Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel Core i5 12th Gen, Intel Core i5 13th Gen, Intel Core i5 14th Gen, Intel Core i7 12th Gen, Intel Core i7 13th Gen, Intel Core i7 14th Gen, Intel Core i9 12th Gen, Intel Core i9 13th Gen, Intel Core i9 14th Gen, Intel® Pentium® Gold
EPS power connector (8-pin)
Front panel audio connector
Supported processor sockets	LGA 1700
ATX Power connector (24-pin)
Number of CPU fan connectors
Number of RGB LED pin headers	2
Number of SATA III connectors	4
Supported memory clock speeds	4400,4800,5200,5600 MHz
Supported storage drive types	HDD & SSD
PCI Express x1 (Gen 3.x) slots	2
PCI Express x16 (Gen 4.x) slots
Maximum internal memory per slot	48 GB
Number of chassis fan connectors	3
Number of storage drives supported	6
Products per shipping (inner) case	1 pc(s)
Supported memory clock speed (max)	5600 MHz
Supported storage drive interfaces	M.2, PCI Express 4.0, SATA III
Windows operating systems supported	Windows 10 x64, Windows 11 x64
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
1st M.2 highest PCI Express generation	4.0
2nd M.2 highest PCI Express generation	4.0
Number of EPS power connectors (8-pin)
Parallel processing technology support	Not supported
System Management BIOS (SMBIOS) version	2.7
Desktop Management Interface (DMI) version	2.7
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Технические данные
Warranty period	3 year(s)
Вес и размеры
Depth	244 mm
Width	244 mm
Height	35 mm
Упаковка
Вес брутто	1,2 кг
Глубина брутто	265 мм
Ширина брутто	265 мм
Высота брутто	54 мм
Screws included
Antenna included
Bundled software	Norton® Internet Security (OEM version) LAN bandwidth management software
Batteries included
