TP-Link

TP-Link TL-SG1218MP tīkla pārslēgs Nepārvaldīts Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Melns

Komutatori (Switch) un barošana

196.36 € PVN iekļauts

Noliktavā · 16

TP-Link TL-SG1218MP, Nepārvaldīts, Gigabit Ethernet (10/100/1000), Pilns duplekss, Power over Ethernet (PoE), Statņa montāža, 1U

TP-Link TL-SG1218MP. Slēdža tips: Nepārvaldīts. Basic switching RJ-45 Ethernet portu veids: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet portu daudzums: 18. Pilns duplekss. Adrešu tabulas izmērs: 8000 ieraksti, Komutācijas ietilpība: 36 Gbit/s. Tīkla standarts: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x. Power over Ethernet (PoE). Statņa montāža, Formas faktors: 1U

  • Nepārvaldīts
  • Quality of Service (QoS) atbalsts
  • Basic switching RJ-45 Ethernet portu daudzums: 18
  • Cat3, Cat4, Cat5, Cat5e, Cat6
  • Adrešu tabulas izmērs: 8000 ieraksti Komutācijas ietilpība: 36 Gbit/s
  • 1U Statņa montāža
  • AC Strāvas barošana iekļauta Power over Ethernet (PoE)

Specifikācija

Galvenie parametri
Garantija 60 mēn.
Korpusa materiāls Metāls
Korpusa tips 1U
Slēdža tips Unmanaged
Maiņstrāvas frekvence 50 - 60 Hz
Maiņstrāvas spriegums 100 - 240 V
10G support No
Full duplex Yes
Half duplex Yes
Jumbo frames 10000
Power source AC
Certification CE, FCC, RoHS
Rack mounting Yes
Auto MDI/MDI-X Yes
LED indicators Yes
Number of fans 2 fan(s)
Product colour Black
Forwarding rate 26.78 Mpps
Auto-negotiation Yes
Heat dissipation 977.44 BTU/h
MAC address table 8000 entries
Switching capacity 36 Gbit/s
Flow control support Yes
Jumbo frames support Yes
Networking standards IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Packet buffer memory 4.1 MB
Cable types supported Cat3, Cat4, Cat5, Cat5e, Cat6
Power supply included Yes
Traffic classification Yes
Ethernet LAN data rates 10,100,1000 Mbit/s
Power consumption (max) 286.64 W
Combo SFP ports quantity 2
Power over Ethernet (PoE) Yes
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 50 °C
Storage relative humidity (H-H) 5 - 90%
MAC address auto-aging supported Yes
Quality of Service (QoS) support Yes
Operating relative humidity (H-H) 10 - 90%
MAC address auto-learning supported Yes
Total Power over Ethernet (PoE) budget 250 W
Gigabit Ethernet (copper) ports quantity 18
Power over Ethernet (PoE) power per port 30 W
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity 18
Power over Ethernet plus (PoE+) ports quantity 16
Svars un izmēri
Depth 180 mm
Width 440 mm
Height 44 mm
Iepakojums
Bruto svars 3,05 kg
Bruto dziļums 528 mm
Bruto platums 250 mm
Bruto augstums 80 mm
Cables included AC
Quick start guide Yes
