TP-Link

TP-Link TL-SG1210P tīkla pārslēgs Nepārvaldīts Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Pelēks

Komutatori (Switch) un barošana

80.28 € PVN iekļauts

Noliktavā · 6

TP-Link TL-SG1210P, Nepārvaldīts, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Pie sienas piestiprināms

TP-Link TL-SG1210P. Slēdža tips: Nepārvaldīts. Basic switching RJ-45 Ethernet portu veids: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet portu daudzums: 9. Adrešu tabulas izmērs: 4000 ieraksti, Komutācijas ietilpība: 20 Gbit/s. Tīkla standarts: IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x. DC ievades spriegums: 53.5 V. Power over Ethernet (PoE). Pie sienas piestiprināms

  • Nepārvaldīts
  • Quality of Service (QoS) atbalsts
  • Basic switching RJ-45 Ethernet portu daudzums: 9
  • 10BASE-T, 100BASE-TX, 1000BASE-T
  • Adrešu tabulas izmērs: 4000 ieraksti Komutācijas ietilpība: 20 Gbit/s
  • Power over Ethernet (PoE)

Specifikācija

Galvenie parametri
Garantija 60 mēn.
Korpusa materiāls Metāls
Slēdža tips Unmanaged
Fanless Yes
Fiber type Single-mode
10G support No
Certification CE, FCC, RoHS
IGMP snooping Yes
Input current 1.31 A
Auto MDI/MDI-X Yes
LED indicators Yes
Product colour Grey
Wall mountable Yes
Auto-negotiation Yes
DC input voltage 53.5 V
Heat dissipation 266.42 BTU/h
MAC address table 4000 entries
Store-and-forward Yes
Switching capacity 20 Gbit/s
Networking standards IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
Power supply included No
Power consumption (max) 78.13 W
Power over Ethernet (PoE) Yes
SFP module slots quantity 1
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 50 °C
Power consumption (typical) 7.11 W
Storage relative humidity (H-H) 5 - 90%
MAC address auto-aging supported Yes
Quality of Service (QoS) support Yes
Fiber ethernet cabling technology 1000BASE-X
Operating relative humidity (H-H) 10 - 90%
Copper ethernet cabling technology 10BASE-T, 100BASE-TX, 1000BASE-T
MAC address auto-learning supported Yes
Total Power over Ethernet (PoE) budget 63 W
Gigabit Ethernet (copper) ports quantity 9
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity 9
Power over Ethernet plus (PoE+) ports quantity 8
Svars un izmēri
Depth 126 mm
Width 209 mm
Height 26 mm
Iepakojums
Manual Yes
User guide Yes
Cables included AC
Quick start guide Yes
