Gigabyte

GIGABYTE H610M D3W DDR4 mātes plate Intel H610 LGA 1700 mikro ATX

Mātesplates (Motherboard)

77.58 € PVN iekļauts

Noliktavā · 3

GIGABYTE H610M D3W DDR4, Intel, LGA 1700, Intel® Celeron®, Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel..., LGA 1700, DDR4-SDRAM, 64 GB

GIGABYTE H610M D3W DDR4. Procesora ražotājs: Intel, Procesora ligzda: LGA 1700, Savietojami procesori: Intel® Celeron®, Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel.... Atbalstītās atmiņas veidi: DDR4-SDRAM, Maksimālā iekšējā atmiņa: 64 GB, Atmiņas slotu tips: DIMM. Atbalstītie glabāšanas diska interfeisi: M.2, SATA III, Atbalstītie atmiņas disku veidi: HDD & SSD. Ethernet interfeisa tips: Tīkls Gigabit Ethernet, LAN kontrollers: Realtek RTL8111H. Komponente: PC (dators), Mātes plates formas faktors: mikro ATX, Mātesplates mikroshēmojuma saime: Intel

  • Intel LGA 1700 Intel® Celeron®, Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel Core i5 12th Gen, Intel Core i5 13th Gen, Intel Core i5 14th Gen, Intel Core i7 12th Gen, Intel Core i7 13th Gen, Intel Core i7 14th Gen, Intel Core i9 12th Gen, Intel Core i9 13th Gen, Intel Core i9 14th Gen, Intel® Pentium®
  • PC (dators) mikro ATX Intel H610 Realtek ALC897 7.1 kanāli
  • DDR4-SDRAM 2 DIMM Maksimālā iekšējā atmiņa: 64 GB
  • HDD & SSD M.2, SATA III Atbalstītais uzglabāšanas diskdziņu skaits: 5
  • BIOS tips: UEFI AMI 128 Mbit ACPI versija: 5.0 Nodzēst CMOS savienotājvads
  • Tīkls Gigabit Ethernet

Specifikācija

Galvenie parametri
Baterijas tips CR2032
Garantija 36 mēn.
Izcelsmes valsts China
Wi-Fi
Line-in
BIOS type UEFI AMI
Audio chip Realtek ALC897
ACPI version 5.0
Ethernet LAN
HDMI version 2.1
Component for PC
Microphone in
TPM connector
Battery weight 3 g
LAN controller Realtek RTL8111H
Product colour Grey
DirectX version 12.0
Memory channels Dual-channel
BIOS memory size 128 Mbit
Processor socket LGA 1700
CPU fan connector
Clear CMOS jumper
Memory slots type DIMM
Power source type ATX
Unbuffered memory
Battery technology Lithium-Manganese Dioxide (LiMnO2)
USB 2.0 connectors
DisplayPort version 1.2
HDMI ports quantity
Motherboard chipset Intel H610
Serial port headers
PC health monitoring Fan, Temperature, Voltage, Water cooling
Audio output channels 7.1 channels
DisplayPorts quantity
Front panel connector
Number of memory slots 2
Processor manufacturer Intel
Supported memory types DDR4-SDRAM
USB 2.0 ports quantity 4
Ethernet interface type Gigabit Ethernet
Maximum internal memory 64 GB
Motherboard form factor micro ATX
Number of M.2 (M) slots
Number of battery cells
1st M.2 largest key size 2280
Number of HDDs supported 4
Ethernet LAN (RJ-45) ports
Lithium weight per battery 0.07 g
Motherboard chipset family Intel
Compatible processor series Intel® Celeron®, Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel Core i5 12th Gen, Intel Core i5 13th Gen, Intel Core i5 14th Gen, Intel Core i7 12th Gen, Intel Core i7 13th Gen, Intel Core i7 14th Gen, Intel Core i9 12th Gen, Intel Core i9 13th Gen, Intel Core i9 14th Gen, Intel® Pentium®
EPS power connector (8-pin)
Front panel audio connector
Supported processor sockets LGA 1700
ATX Power connector (24-pin)
Number of CPU fan connectors
Number of SATA III connectors 4
Supported memory clock speeds 2133,2400,2666,2933,3000,3200 MHz
Supported storage drive types HDD & SSD
PCI Express x1 (Gen 3.x) slots
PCI Express x16 (Gen 4.x) slots
Maximum internal memory per slot 32 GB
Number of chassis fan connectors 2
Number of storage drives supported 5
Products per shipping (inner) case 1 pc(s)
Supported memory clock speed (max) 3200 MHz
Supported storage drive interfaces M.2, SATA III
Windows operating systems supported Windows 10, Windows 11
USB 3.2 Gen 1 (3.1 Gen 1) connectors 2
1st M.2 highest PCI Express generation 3.0
Number of EPS power connectors (8-pin)
Parallel processing technology support Not supported
System Management BIOS (SMBIOS) version 2.7
Desktop Management Interface (DMI) version 2.7
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
Tehniskie dati
Warranty period 3 year(s)
Svars un izmēri
Depth 220 mm
Width 244 mm
Height 35 mm
Iepakojums
Bruto svars 0,8 kg
Bruto dziļums 265 mm
Bruto platums 265 mm
Bruto augstums 54 mm
Screws included
Bundled software Norton® Internet Security (OEM version) LAN bandwidth management software
Batteries included
