ASUS B860M MAX GAMING AX Intel B860 LGA 1851 (Socket V1) mikro ATX

Name: ASUS B860M MAX GAMING AX Intel B860 LGA 1851 (Socket V1) mikro ATX
Brand: Asus
SKU: B860M MAX GAMING AX
Price: 177.44 EUR
Availability: InStock

Mātesplates (Motherboard)

177.44 € PVN iekļauts

Noliktavā · 97

ASUS B860M MAX GAMING AX, Intel, LGA 1851 (Socket V1), Intel Core Ultra (Series 2), LGA 1851, DDR5-SDRAM, 256 GB

ASUS B860M MAX GAMING AX. Procesora ražotājs: Intel, Procesora ligzda: LGA 1851 (Socket V1), Savietojami procesori: Intel Core Ultra (Series 2). Atbalstītās atmiņas veidi: DDR5-SDRAM, Maksimālā iekšējā atmiņa: 256 GB, Atmiņas slotu tips: DIMM. Atbalstītie glabāšanas diska interfeisi: PCI Express 4.0, PCI Express 5.0, Atbalstītie atmiņas disku veidi: HDD & SSD, RAID līmeņi: 0, 1, 5, 10. Maksimālā izšķirtspēja: 3840 x 2160 pikseļi. Ethernet interfeisa tips: 2.5 Gigabit Ethernet, Wi-Fi standarts: Wi-Fi 6 (802.11ax), Wi-Fi standartu: Wi-Fi 6 (802.11ax)

Intel LGA 1851 (Socket V1) Intel Core Ultra (Series 2)
PC (dators) mikro ATX Intel B860 7.1 kanāli
DDR5-SDRAM 4 DIMM Maksimālā iekšējā atmiņa: 256 GB
HDD & SSD PCI Express 4.0, PCI Express 5.0 Atbalsta RAID Atbalstītais uzglabāšanas diskdziņu skaits: 7
BIOS tips: UEFI AMI 256 Mbit
2.5 Gigabit Ethernet Wi-Fi Wi-Fi 6 (802.11ax) Bluetooth 5.3

Specifikācija

Galvenie parametri
Garantija	36 mēn.
Bezvadu
Bluetooth versija	5.3
Wi-Fi
Line-in
BIOS type	UEFI AMI
RAID levels	0, 1, 5, 10
Cooling type	Passive
Ethernet LAN
RAID support
Component for	PC
Microphone in
TPM connector
Product colour	Grey
Memory channels	Dual-channel
Wi-Fi standards	Wi-Fi 6 (802.11ax)
BIOS memory size	256 Mbit
Processor socket	LGA 1851 (Socket V1)
CPU fan connector
Memory slots type	DIMM
Power source type	ATX
Unbuffered memory
Maximum resolution	3840 x 2160 pixels
RGB LED pin header
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
USB 2.0 connectors	3
12V power connector
DisplayPort version	1.4
Motherboard chipset	Intel B860
S/PDIF out connector
WiFi-AP antenna jack	2
Audio output channels	7.1 channels
DisplayPorts quantity
Front panel connector
Number of memory slots	4
Processor manufacturer	Intel
Supported memory types	DDR5-SDRAM
USB 2.0 ports quantity	4
Ethernet interface type	2.5 Gigabit Ethernet
Maximum internal memory	256 GB
Motherboard form factor	micro ATX
Number of M.2 (M) slots	3
1st M.2 largest key size	2280
2nd M.2 largest key size	2280
3rd M.2 largest key size	2280
Number of HDDs supported	4
Ethernet LAN (RJ-45) ports
Motherboard chipset family	Intel
Chassis intrusion connector
Compatible processor series	Intel Core Ultra (Series 2)
EPS power connector (8-pin)
Front panel audio connector
Supported processor sockets	LGA 1851
ATX Power connector (24-pin)
Number of CPU fan connectors
Number of RGB LED pin headers	3
Number of SATA III connectors	4
Supported storage drive types	HDD & SSD
Number of water pump connectors
PCI Express x16 (Gen 4.x) slots	3
PCI Express x16 (Gen 5.x) slots
Maximum internal memory per slot	64 GB
Number of chassis fan connectors	4
Number of storage drives supported	7
Supported memory clock speed (max)	8666 MHz
Supported storage drive interfaces	PCI Express 4.0, PCI Express 5.0
Windows operating systems supported	Windows 10 x64, Windows 11
USB 3.2 Gen 1 (3.1 Gen 1) connectors
USB 3.2 Gen 2 (3.1 Gen 2) connectors
USB 3.2 Gen 2x2 Type-C ports quantity
1st M.2 highest PCI Express generation	5.0
2nd M.2 highest PCI Express generation	4.0
3rd M.2 highest PCI Express generation	4.0
Number of EPS power connectors (8-pin)
Parallel processing technology support	Not supported
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Svars un izmēri
Depth	244 mm
Width	244 mm
Citi
Quick installation guide
Iepakojums
Cables included	SATA
Screws included
Antenna included
