iiyama TE8613A-B2AG ceļrāžu displejs Kioska dizains 2,17 m (85.6") Wi-Fi 500 cd/m² 4K Ultra HD Melns Skārienjūtīgais ekrāns Iebūvētais procesors Android 24/7

Name: iiyama TE8613A-B2AG ceļrāžu displejs Kioska dizains 2,17 m (85.6") Wi-Fi 500 cd/m² 4K Ultra HD Melns Skārienjūtīgais ekrāns Iebūvētais procesors Android 24/7
Brand: Iiyama
SKU: TE8613A-B2AG
Price: 2472.24 EUR
Availability: InStock

Monitori

2 472.24 € PVN iekļauts

Noliktavā · 1

iiyama TE8613A-B2AG, Kioska dizains, 2,17 m (85.6"), 3840 x 2160 pikseļi, Wi-Fi, 24/7

iiyama TE8613A-B2AG. Produkta dizains: Kioska dizains. Displeja diagonāle: 2,17 m (85.6"), Ekrāna izšķirtspēja: 3840 x 2160 pikseļi, Ekrāna spilgtums: 500 cd/m², HD veids: 4K Ultra HD, Skārienjūtīgais ekrāns. Wi-Fi. Ekspluatācijas ilgums (stundas/dienas): 24/7. Nodrošināta operētājsistēma: Android. Produkta krāsa: Melns

Iekštelpas Kioska dizains Melns
2,17 m (85.6") 3840 x 2160 pikseļi 500 cd/m²
Skārienjūtīgais ekrāns 60 Hz 8 ms
Ethernet/LAN savienojums Wi-Fi
Iebūvēti skaļruņi 60 W

Specifikācija

Galvenie parametri
Garantija	24 mēn.
Ekrāna diagonāle	2.17 m (85.6")
Paneļa tips	IPS
Reakcijas laiks	8 ms
HD tips	4K Ultra HD
Maiņstrāvas frekvence	50/60 Hz
Maiņstrāvas spriegums	100 - 240 V
HDCP
Wi-Fi
Purpose	Education
RS-232C
USB port
Orientation	Horizontal
Pixel pitch	0.493 x 0.493 mm
Touchscreen
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
Bezel colour	Black
Ethernet LAN
HDCP version	2.2
HDMI version	2.0
VESA mounting
Product colour	Black
Product design	Kiosk design
Computer system
Glass thickness	3.2 mm
Internal memory	8 GB
OPS module slot
Processor cores	4
RMS rated power	60 W
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Surface hardness	7H
Anti-glare screen
Bezel width (top)	1.65 cm
Bezel width (side)	1.65 cm
Built-in processor
Display brightness	500 cd/m²
Display resolution	3840 x 2160 pixels
USB connector type	USB Type-A, USB Type-B, USB Type-C
USB ports quantity	6
Built-in speaker(s)
DisplayPort version	1.2
HDMI ports quantity	3
Native aspect ratio	16:9
Native refresh rate	60 Hz
Placement supported	Indoor
Processor frequency	1.4 GHz
Touch response time	5 ms
Bezel width (bottom)	4.1 cm
Positioning accuracy	1 mm
DisplayPorts quantity
Horizontal scan range	30 - 135 kHz
Card reader integrated
Processor architecture	ARM Cortex-A73
Touchscreen technology	PureTouch-IR
Compatible memory cards	MicroSD (TransFlash)
Energy efficiency scale	A to G
Ethernet LAN data rates	1000 Mbit/s
Number of OSD languages	13
On Screen Display (OSD)
Power consumption (off)	0.3 W
Viewing angle, vertical	178°
Contrast ratio (dynamic)	5000:1
Contrast ratio (typical)	1200:1
Operating system version	14
Panel mounting interface	800 x 600 mm
USB Power Delivery up to	100 W
Display diagonal (metric)	217.4 cm
Display number of colours	1.07 billion colours
HDMI input ports quantity
Internal storage capacity	128 GB
Storage temperature (T-T)	-20 - 60 °C
Viewing angle, horizontal	178°
Audio Return Channel (ARC)
Ethernet LAN (RJ-45) ports	2
HDMI output ports quantity
Operating system installed	Android
Active display area (W x H)	1895 x 1066 mm
Number of built-in speakers	2
Operating temperature (T-T)	0 - 40 °C
Power consumption (standby)	0.5 W
Power consumption (typical)	282 W
USB Power Delivery (USB PD)
On-board graphics card model	ARM Mali-G52
Operating hours (hours/days)	24/7
Energy efficiency class (HDR)	Not available
Energy efficiency class (SDR)	G
USB 2.0 Type-B ports quantity
Mean time between failures (MTBF)	50000 h
On Screen Display (OSD) languages	Czech, Danish, German, English, Spanish, Estonian, Finnish, French, Hungarian, Italian, Lithuanian, LAT, Norwegian, Dutch, Polish, Russian, Swedish, Ukrainian
Number of simultaneous touchpoints	40
USB Type-C DisplayPort Alternate Mode
Energy consumption (SDR) per 1000 hours	260 kWh
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	2
Tehniskie dati
OPS slot
User controls	general settings (input, volume, backlight), audio (volume, bass, treble, balance, sound mode, mute), screen settings (aspect ratio, pixel shift), display settings (brightness, contrast, hue, sharpness, display mode colour temp), settings (wireless & networks, share, device, personal, system)
Playback media
Warranty period	5 year(s)
Audio in (mini jack)
Compliance certificates	CB, CE, EAC, REACH, RoHS, TÜV mark, WEEE
Sustainability certificates	ErP
Svars un izmēri
Depth	87.1 mm
Width	1955.6 mm
Height	1154 mm
Display depth	87.1 mm
Display width	1955.6 mm
Display height	1154 mm
Display weight	63.8 kg
Citi
Bezvadu
Bluetooth versija	5.0
Spilgtums	500 cd/m²
Power supply type	Internal
Quick start guide
Compatible operating systems	All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Iepakojums
Bruto svars	76,5 kg
Bruto dziļums	185 mm
Bruto platums	2095 mm
Bruto augstums	1265 mm
Stylus pen
Cables included	AC, USB, HDMI
Number of stylus pens	4
Remote control included
