Chieftec Core BBS-700S barošanas avotu vienība 700 W 24-pin ATX PS/2 Melns

Name: Chieftec Core BBS-700S barošanas avotu vienība 700 W 24-pin ATX PS/2 Melns
Brand: Chieftec
SKU: BBS-700S
Price: 75.68 EUR
Availability: InStock

Datoru kabeļi

75.68 € PVN iekļauts

Noliktavā · 50

Chieftec Core BBS-700S, 700 W, 100 - 240 V, 47 - 63 Hz, 10 A, Aktīvs, 3,6 W

Chieftec Core BBS-700S. Kopējā jauda: 700 W, Maiņstrāvas ievades spriegums: 100 - 240 V, Maiņstrāvas ievades frekvence: 47 - 63 Hz. Mātesplates strāvas konektors: 24-pin ATX, SATA strāvas kabeļa garums: 150,500 mm, Periferālā (Molex) strāvas kabeļa garums: 150,500 mm. Mērķis, rezultāts: PC (dators), Strāvas padeves bloka (PSU) formas faktors: PS/2, 80 PLUS sertifikācija: 80 PLUS Gold. Produkta krāsa: Melns, Dzesēšanas tips: Aktīvs, Ventilatora diametrs: 12 cm. Platums: 140 mm, Dziļums: 150 mm, Augstums: 86 mm

700 W 100 - 240 V 47 - 63 Hz
Mātesplates strāvas konektors: 24-pin ATX
PC (dators) PS/2 80 PLUS Gold
Aktīvs 12 cm
Melns

Specifikācija

Galvenie parametri
Garantija	24 mēn.
Maiņstrāvas frekvence	47 - 63 Hz
Maiņstrāvas spriegums	100 - 240 V
Purpose	PC
Total power	700 W
Cabling type	Non-Modular
Cooling type	Active
Fan diameter	12 cm
Input current	10 A
Number of fans	1 fan(s)
Product colour	Black
80 PLUS certification	80 PLUS Gold
Combined power (-12V)	3.6 W
CPU power cable length	65 cm
Combined power (+5Vsb)	12.5 W
SATA power cable length	150,500 mm
Max output current (+5V)	22 A
Max output current (-12V)	0.3 A
Power protection features	Over voltage, Overload, Short circuit
Max output current (+12V1)	58 A
Max output current (+3.3V)	22 A
Max output current (+5Vsb)	2.5 A
Floppy disk drive connector	Yes
Motherboard power connector	24-pin ATX
Floppy drive power connector	1
CPU power connector (4+4 pin)	Yes
PCI Express power cable length	50 cm
Number of SATA power connectors	6
Power Factor Correction (PFC) type	Active
Power supply unit (PSU) form factor	PS/2
Peripheral (Molex) power cable length	150,500 mm
PCI Express power connectors (6+2 pin)	4
Peripheral (Molex) power connectors (4-pin)	3
Svars un izmēri
Depth	150 mm
Width	140 mm
Height	86 mm
Iepakojums
Bruto svars	2,13 kg
