FSP VITA-850BD-B barošanas avotu vienība 850 W 20+4 pin ATX ATX Melns

Name: FSP VITA-850BD-B barošanas avotu vienība 850 W 20+4 pin ATX ATX Melns
Brand: Fortron
SKU: 9PA8508201
Price: 70.06 EUR
Availability: InStock

Barošanas bloki (PSU)

70.06 € PVN iekļauts

Noliktavā · 8

FSP VITA-850BD-B, 850 W, 200 - 240 V, 50/60 Hz, 5.5 A, Aktīvs, 100 W

FSP VITA-850BD-B. Kopējā jauda: 850 W, Maiņstrāvas ievades spriegums: 200 - 240 V, Maiņstrāvas ievades frekvence: 50/60 Hz. Mātesplates strāvas konektors: 20+4 pin ATX, Mātesplates barošanas vada garums: 60 cm, SATA strāvas kabeļa garums: 500 mm. Mērķis, rezultāts: PC (dators), Strāvas padeves bloka (PSU) formas faktors: ATX, 80 PLUS sertifikācija: 80 PLUS Bronze. Produkta krāsa: Melns, Dzesēšanas tips: Aktīvs, Ventilatora diametrs: 12 cm. Pievienoti kabeļi: Centrālais procesors, Peripheral (Molex), SATA

850 W 200 - 240 V 50/60 Hz
Mātesplates strāvas konektors: 20+4 pin ATX
PC (dators) ATX 80 PLUS Bronze
Aktīvs 12 cm
Melns

Specifikācija

Galvenie parametri
Maiņstrāvas frekvence	50/60 Hz
Maiņstrāvas spriegums	200 - 240 V
Purpose	PC
Efficiency	90%
ATX version	3.1
EPS version	2.92
Total power	850 W
Cabling type	Non-Modular
Cooling type	Active
Fan diameter	12 cm
Fan location	Top
Input current	5.5 A
Number of fans	1 fan(s)
Product colour	Black
Bearing technology	HYB
Combined power (+5V)	100 W
80 PLUS certification	80 PLUS Bronze
Combined power (+12V)	850 W
Combined power (-12V)	3.6 W
CPU power cable length	70 cm
Combined power (+3.3V)	100 W
Combined power (+5Vsb)	15 W
SATA power cable length	500 mm
Max output current (+5V)	20 A
Max output current (+12V)	70.83 A
Max output current (-12V)	0.3 A
Power protection features	Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Max output current (+3.3V)	20 A
Max output current (+5Vsb)	3 A
Motherboard power connector	20+4 pin ATX
CPU power connector (4+4 pin)
Motherboard power cable length	60 cm
Number of SATA power connectors	8
Power Factor Correction (PFC) type	Active
Power supply unit (PSU) form factor	ATX
PCI Express power connectors (6+2 pin)	4
Peripheral (Molex) power connectors (4-pin)	4
Svars un izmēri
Depth	140 mm
Width	150 mm
Height	86 mm
Iepakojums
Cables included	CPU, Peripheral (Molex), SATA
