FSP CANNON PRO(ATX3.1) 2500W barošanas avotu vienība 20+4 pin ATX ATX Melns

Name: FSP CANNON PRO(ATX3.1) 2500W barošanas avotu vienība 20+4 pin ATX ATX Melns
Brand: Fortron
SKU: PPA25A0102
Price: 540.60 EUR
Availability: InStock

Barošanas bloki (PSU)

446.78 € bez PVN

Noliktavā · 2

FSP CANNON PRO(ATX3.1) 2500W, 2500 W, 200 - 240 V, 50/60 Hz, 15 - 12 A, Aktīvs, 125 W

FSP CANNON PRO(ATX3.1) 2500W. Kopējā jauda: 2500 W, Maiņstrāvas ievades spriegums: 200 - 240 V, Maiņstrāvas ievades frekvence: 50/60 Hz. Mātesplates strāvas konektors: 20+4 pin ATX, SATA strāvas kabeļa garums: 965 mm, Periferālā (Molex) strāvas kabeļa garums: 965 mm. Mērķis, rezultāts: PC (dators), Strāvas padeves bloka (PSU) formas faktors: ATX, 80 PLUS sertifikācija: 80 PLUS Platinum. Produkta krāsa: Melns, Ventilatora diametrs: 13,5 cm, Ventilatoru skaits: 1 ventilators/ ventilatori. Platums: 150 mm, Dziļums: 200 mm, Augstums: 86 mm

2500 W 200 - 240 V 50/60 Hz
Mātesplates strāvas konektors: 20+4 pin ATX
PC (dators) ATX 80 PLUS Platinum
13,5 cm
Melns

Specifikācija

Galvenie parametri
Garantija	36 mēn.
Maiņstrāvas frekvence	50/60 Hz
Maiņstrāvas spriegums	200 - 240 V
Purpose	PC
Efficiency	94%
ATX version	3.1
Total power	2500 W
Cabling type	Fully-Modular
Fan diameter	13.5 cm
Fan location	Top
Power factor	0.9
Input current	15 - 12 A
On/off switch
Number of fans	1 fan(s)
Product colour	Black
Bearing technology	FDB
Combined power (+5V)	125 W
80 PLUS certification	80 PLUS Platinum
Combined power (+12V)	2499.6 W
Combined power (-12V)	3.6 W
Combined power (+3.3V)	125 W
Combined power (+5Vsb)	20 W
SATA power cable length	965 mm
Max output current (+5V)	25 A
Max output current (+12V)	208.3 A
Max output current (-12V)	0.3 A
Power protection features	No load operation, Over current, Over power, Over voltage, Short circuit, Surge and inrush, Under temperature, Under voltage
Max output current (+3.3V)	25 A
Max output current (+5Vsb)	4 A
Motherboard power connector	20+4 pin ATX
Number of SATA power cables	2
CPU power connector (4+4 pin)
ATX power connector (20+4 pin)
Number of SATA power connectors	8
Power Factor Correction (PFC) type	Active
Power supply unit (PSU) form factor	ATX
PCI Express power connectors (8-pin)	8
Peripheral (Molex) power cable length	965 mm
PCI Express power connectors (6+2 pin)	3
Peripheral (Molex) power connectors (4-pin)	4
Svars un izmēri
Depth	200 mm
Width	150 mm
Height	86 mm
