ASUS Pro WS 2200W Platinum barošanas avotu vienība 20+4 pin ATX ATX Melns

Name: ASUS Pro WS 2200W Platinum barošanas avotu vienība 20+4 pin ATX ATX Melns
Brand: Asus
SKU: 90YE00Z1-B0NA00
Price: 519.02 EUR
Availability: InStock

Barošanas bloki (PSU)

519.02 € PVN iekļauts

Noliktavā · 11

ASUS Pro WS 2200W Platinum, 2200 W, 200 - 240 V, Aktīvs, 130 W, 2200 W, 130 W

ASUS Pro WS 2200W Platinum. Kopējā jauda: 2200 W, Maiņstrāvas ievades spriegums: 200 - 240 V, Strāvas faktora korekcija (PFC) veids: Aktīvs. Mātesplates strāvas konektors: 20+4 pin ATX, Mātesplates barošanas vada garums: 61 cm, SATA strāvas kabeļa garums: 120,400 mm. Mērķis, rezultāts: PC (dators), Strāvas padeves bloka (PSU) formas faktors: ATX, 80 PLUS sertifikācija: 80 PLUS Platinum. Produkta krāsa: Melns, Dzesēšanas tips: Aktīvs. Atbilstības sertifikāti: RoHS

2200 W 200 - 240 V
Mātesplates strāvas konektors: 20+4 pin ATX
PC (dators) ATX 80 PLUS Platinum
Aktīvs
Melns

Specifikācija

Galvenie parametri
Garantija	120 mēn.
Maiņstrāvas spriegums	200 - 240 V
Purpose	PC
Efficiency	92%
ATX version	3.1
Total power	2200 W
Cabling type	Fully-Modular
Cooling type	Active
Illumination
On/off switch
Product colour	Black
Warranty period	10 year(s)
Bearing technology	Ball bearing
Combined power (+5V)	130 W
80 PLUS certification	80 PLUS Platinum
Combined power (+12V)	2200 W
Combined power (-12V)	9.6 W
PCI Express connector
CPU power cable length	100 cm
Combined power (+3.3V)	130 W
Combined power (+5Vsb)	15 W
Compliance certificates	RoHS
SATA power cable length	120,400 mm
Max output current (+5V)	25 A
Max output current (+12V)	183.3 A
Max output current (-12V)	0.8 A
Power protection features	Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Max output current (+3.3V)	25 A
Max output current (+5Vsb)	3 A
Motherboard power connector	20+4 pin ATX
CPU power connector (4+4 pin)
ATX power connector (20+4 pin)
Motherboard power cable length	61 cm
PCI Express power cable length	75 cm
Number of SATA power connectors	12
Power Factor Correction (PFC) type	Active
Power supply unit (PSU) form factor	ATX
PCI Express power connectors (16-pin)	4
Peripheral (Molex) power cable length	150,400 mm
PCI Express power connectors (6+2 pin)	4
Peripheral (Molex) power connectors (4-pin)	3
Svars un izmēri
Depth	175 mm
Width	150 mm
Height	86 mm
Iepakojums
Bruto svars	5,06 kg
Bruto dziļums	208 mm
Bruto platums	346 mm
Bruto augstums	144 mm
Iepakojuma tips	Box
