Club 3D

CLUB3D CSV-2562 13-1 Thunderbolt™ 5 Docking Station M.2 SSD 2x HDMI™ 8K60Hz Thunderbolt™ Share Certified 180W

Audio and video cables

290.55 € VAT included

In stock · 5

CLUB3D CSV-2562 13-1 Thunderbolt™ 5 Docking Station M.2 SSD 2x HDMI™ 8K60Hz Thunderbolt™ Share Certified 180W, Wired, Thunderbolt 5, 140 W, 3.5 mm, 10,100,1000,2500 Mbit/s, Black

Description:• CERTIFIED THUNDERBOLT™ 5 - Our highest model TB5 device, fully certified for guaranteed compatibility and peak performance.• EXPAND STORAGE HASSLE-FREE - Add more space with an easy-to-use SSD slot, giving your computer the same lightning-fast speed as its built-in storage.• POWER YOUR WHOLE SETUP - Delivers 140W to your laptop + 30W to phones/tablets via two front-facing USB-C® ports (no extra chargers needed).• THUNDERBOLT™ SHARE INCLUDED - Comes with a Thunderbolt™ Share license to connect two computers directly for seamless file transfer and display control.

  • Features:
  • Adopting Barlow Ridge solution
  • Compatible with SSDs in 2280, 2260, 2242, and 2230 sizes
  • supporting PCIe Gen4x4 (16Gbps, 4 lanes) with maximum read and
  • write speeds of 6000MB/s
  • Designed for TB5/TB4/USB4 based PCs and compatible with TB3/
  • DP-Alt-mode PCs
  • Support Thunderbolt™ 5 max 80Gbps or 120Gbps for high speed data
  • and outstanding video transfer
  • Downstream ports allow you to cascade Thunderbolt™ devices up to 5
  • levels
  • Downstream ports support max. 80Gbps or 120Gbps data transfer
  • support Type-C® dongle/adapter/dock
  • Support max 10K60Hz for one video output and to be more efficient
  • 5K60Hz or 4K144Hz for triple
  • Self-powered from DC power adapter with max. 180Watt for host and
  • Hub
  • Made from recycled materials (PCR). Sustainable and durable
  • The device has standard and nano Kensington lock slots for a secure
  • anti-theft mechanism

Specifications

Features
Warranty 24 mo.
Body material Plastic
HD type 8K Ultra HD
NVMe
Ethernet LAN
Power supply 180 W
Microphone in
On/off switch
SSD enclosure
Host interface Thunderbolt 5
Product colour Black
Cable lock slot
USB cable length 1 m
Headphone outputs
Power source type DC
Data transfer rate 120 Gbit/s
Built-in speaker(s)
HDMI ports quantity 2
Cable lock slot type Kensington, Nano
Maximum refresh rate 144 Hz
Card reader integrated
Headphone connectivity 3.5 mm
USB 2.0 ports quantity 3
Compatible memory cards MicroSD Express, SD
Connectivity technology Wired
Ethernet LAN data rates 10,100,1000,2500 Mbit/s
USB Power Delivery up to 140 W
Ethernet LAN (RJ-45) ports
Sustainability certificates SCS Product Category Rule (PCR)
Number of displays supported 3
Thunderbolt 5 ports quantity
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 2
Weight & dimensions
Depth 140 mm
Width 140 mm
Height 50 mm
Packaging
Gross weight 1,6 kg
Gross depth 59 mm
Gross width 302 mm
Gross height 169 mm
Quantity in pack 1 pcs
Cables included Thunderbolt
Plastic packaging weight 7 g
Total plastic packaging weight 0 g
Paper/cardboard packaging weight 168 g
Total paper/cardboard packaging weight 0 g
