TP-Link Omada 48-Port Gigabit L2+ Managed Switch with 4 SFP Slots

Name: TP-Link Omada 48-Port Gigabit L2+ Managed Switch with 4 SFP Slots
Brand: TP-Link
SKU: TL-SG3452
Price: 377.99 EUR
Availability: InStock

Switches and power supplies

312.39 € ex VAT

In stock · 8

TP-Link Omada 48-Port Gigabit L2+ Managed Switch with 4 SFP Slots, Managed, L2+, Gigabit Ethernet (10/100/1000), Rack mounting, 1U

TP-Link | Omada L2+ managed switches provide high performance, powerful L2 and L2+ features like static routing, enterprise-level QoS, advanced security strategies and a bundle of ISP features. The IP-MAC-Port Binding (IMPB) and Access Control List (ACL) functions protect against broadcast storm, ARP and Denial-ofService (DoS) attacks, etc. Quality of Service (QoS, L2 to L4) provides enhanced traffic management capabilities to move your data smoother and faster. The OAM and DDM functions help facilitate network management. Moreover, the easy-to-use web management interfaces, along with CLI, SNMP and Dual Image mean faster setup and configuration with less downtime. TP-Link | Omada L2+ managed Switches provide a reliable, secure solution for enterprise, campus and ISP networks.

Full Gigabit Ports: 48× gigabit RJ45 ports and 4× gigabit SFP Slots provide high-speed connections
Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)*, Centralized Cloud Management, and Intelligent Monitoring
Centralized Management: Cloud access and Omada app for ultra convenience and easy management
Static Routing: Helps route internal traffic for more efficient use of network resources
Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more
Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping
Standalone Management: Web, CLI (Console Port, Telnet, SSH), SNMP, RMON, and Dual Image bring powerful management capabilities

Specifications

Features
Warranty	60 mo.
Chassis type	1U
Switch type	Managed
AC input frequency	50/60 Hz
AC input voltage	100 - 240 V
Fanless
IP routing
10G support
IPv4 routes	48
IPv6 routes	48
MIB support
Console port	RJ-45/Micro-USB
Flash memory	32 MB
Jumbo frames	9000
Power source	AC
Static route
Switch layer	L2+
VLAN support
Certification	CE, FCC, RoHS
Cloud-managed
DHCP features	DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 snooping
IGMP snooping
Rack mounting
ARP inspection
Authentication	MAC-based authentication, Port-based authentication
Port mirroring
Product colour	Black
Forwarding rate	77.38 Mpps
Internal memory	256 MB
Loop protection
Number of VLANs	4000
SSH/SSL support
Heat dissipation	118.94 BTU/h
Link aggregation
System event log
MAC address table	16000 entries
Multicast support
Store-and-forward
Switching capacity	104 Gbit/s
Authentication type	AAA, RADIUS, TACACS+
IP-MAC-Port binding
Flow control support
IPv4 & IPv6 features	IPv4/IPv6 access-control list (ACL), IPv6 Telnet, IPv6 ping, IPv6 tracert
Jumbo frames support
Management protocols	SNMPv1/v2c/v3, SNTP
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z
Policy-based routing
Virtual LAN features	Port-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
Web-based management
MAC address filtering
Power supply included
Spanning tree protocol
Broadcast storm control
Ethernet LAN data rates	10,100,1000 Mbit/s
Power consumption (max)	34.86 W
Access Control List (ACL)
BPDU filtering/protection
Power over Ethernet (PoE)
SFP module slots quantity	4
Storage temperature (T-T)	-40 - 70 °C
Head-of-line (HOL) blocking
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90%
Quality of Service (QoS) support
Operating relative humidity (H-H)	10 - 90%
Configuring Location Settings (CLI)
GARP VLAN Registration Protocol (GVRP)
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Multicast Listener Discovery (MLD) snooping
Basic switching RJ-45 Ethernet ports quantity	48
Weight & dimensions
Depth	220 mm
Width	440 mm
Height	44 mm
Packaging
Rack mount kit
Cables included	AC
Quick start guide
