TP-Link Omada ES210GP network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) DIN rail Black

Name: TP-Link Omada ES210GP network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) DIN rail Black
Brand: TP-Link
SKU: ES210GP
Price: 93.29 EUR
Availability: InStock

Switches and power supplies

77.10 € ex VAT

In stock · 3

TP-Link Omada ES210GP, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, DIN rail

TP-Link Omada ES210GP. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 10. MAC address table: 8000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt. DC input voltage: 53 V. Power over Ethernet (PoE). Rack mounting, Form factor: DIN rail

8× Gigabit 802.3af/at-compliant PoE+ RJ45 ports
1× Gigabit RJ45 port, 1× Gigabit SFP/RJ45 Combo port
63W Power Budget, with up to 30W for each PoE port*
Easy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional features
Centralized Cloud Management via the web or the Omada app†
Up to 820ft PoE**, Remote Camera Reboot†, QoS, and Port Isolation for reliable surveillance networking
Automatic Loop Prevention, VLAN, and IGMP Snooping
Fanless design for silent operation
Durable metal casing and desktop/wall mounting design

Specifications

Features
Chassis type	DIN rail
Switch type	Managed
10G support
Jumbo frames	15000
Power source	DC
Switch layer	L2
VLAN support
Cloud-managed
DHCP features	DHCP client
IGMP snooping
Input current	1.31 A
Rack mounting
Auto MDI/MDI-X
LED indicators
Port mirroring
Product colour	Black
Forwarding rate	14.88 Mpps
Loop protection
Number of VLANs	4000
Auto-negotiation
DC input voltage	53 V
Link aggregation
MAC address table	8000 entries
Multicast support
Store-and-forward
Switching capacity	20 Gbit/s
Flow control support
Jumbo frames support
Networking standards	IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Packet buffer memory	0.5 MB
Virtual LAN features	MTU VLAN, Port-based VLAN, Tagged VLAN
Web-based management
Broadcast storm control
Compliance certificates	CE, Federal Communications Commission (FCC), RoHS
Ethernet LAN data rates	10,100,1000 Mbit/s
Combo SFP ports quantity
Power over Ethernet (PoE)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Transmission distance (max)	0.25 km
Storage relative humidity (H-H)	5 - 90%
Quality of Service (QoS) support
Operating relative humidity (H-H)	10 - 90%
Total Power over Ethernet (PoE) budget	63 W
Power over Ethernet (PoE) type supported	PoE+
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	10
Power over Ethernet plus (PoE+) ports quantity	8
Weight & dimensions
Depth	126 mm
Width	209 mm
Height	26 mm
Packaging
Cables included	Power
Quick start guide
