Dahua Technology CS4228-24GT-375 Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

Name: Dahua Technology CS4228-24GT-375 Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Brand: Dahua
SKU: DH-CS4228-24GT-375
Price: 264.37 EUR
Availability: InStock

Switches and power supplies

218.48 € ex VAT

In stock · 3

Dahua Technology CS4228-24GT-375, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting

Highly intuitive, the Smart Managed Switch can manage local networks. With the DoLynk Care platform, it can also perform cloud management. The switch performs operation and maintenance usingtopology visualization on front-end, transmission and back-end storage devices that are in the security system and IT system. With its full metal design, the switch has great heat dissipation and can operate intemperatures ranging -10°C to 55°C. It offers EMC and has protection against overvoltage, overcurrent, static electricity, lightning strikes, pulses and other types of interference. For the PoE series SmartManaged Switch, power is supplied up to 250 meters away. The orange port supplies up to 60 W and the red port provides up to 90 W. Also, link aggregation and STP are available on select models to ensurethe network remains stable. The switch can be used in small and medium-sized businesses such as supermarkets, offices, restaurants, cafés and hotels.

Meets the requirements of IEEE802.3,IEEE802.3u,IEEE802.3x,IEEE802.3ab,IEEE802.3z standards
Meets the requirements of IEEE802.3af, IEEE802.3at, Hi-PoE, and IEEE802.3bt power supply standards
Manages PoE power consumption and PoE power on/off. Supports Intelligent PoE
A wide operating temperature range and a full metal casing that is fully-enclosed and dust-proof

Specifications

Features
Warranty	24 mo.
Body material	Metal
Switch type	Managed
AC input frequency	47/63 Hz
AC input voltage	100 - 240 V
10G support
Power source	AC/DC/PoE
Reset button
Switch layer	L2
VLAN support
Cloud-managed
DHCP features	DHCP client
Input current	7 A
Rack mounting
Product colour	Black
Forwarding rate	41.66 Mpps
Number of VLANs	32
MAC address table	8000 entries
Switching capacity	56 Gbit/s
Flow control support
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Port-based VLAN
Web-based management
Power supply included
Spanning tree protocol
Power over Ethernet (PoE)
SFP module slots quantity	2
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-10 - 55 °C
Power consumption (typical)	400 W
Storage relative humidity (H-H)	5 - 95%
Operating relative humidity (H-H)	5 - 95%
Total Power over Ethernet (PoE) budget	375 W
Power over Ethernet (PoE) ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	26
Weight & dimensions
Depth	220 mm
Width	440 mm
Height	44 mm
Packaging
Gross weight	3,26 kg
Gross depth	342 mm
Gross width	540 mm
Gross height	90 mm
