TP-Link 8-Port Gigabit Desktop PoE Switch with 4-Port

Name: TP-Link 8-Port Gigabit Desktop PoE Switch with 4-Port
Brand: TP-Link
SKU: TLSG1008P8
Price: 47.15 EUR
Availability: InStock

Switches and power supplies

38.97 € ex VAT

In stock · 3

TP-Link 8-Port Gigabit Desktop PoE Switch with 4-Port, Managed, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE)

PoE Switches for Your Ultra Convenience8-Port Gigabit Desktop Switch with 4-Port PoEPower over Ethernet4 of the 5 Auto-Negotiation RJ45 ports (Port 1 to Port 4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).Intelligent Power ManagementWhen total power consumption excels 55W, the intelligent power management will cut the lower priority port power off to ensure the high priority port’s power supply and protect the device from power overload operation.Sturdy Metal CasingSturdy, compact metal casing and shielded RJ45 ports, with desktop, to meet your needs in any environment. Besides, fanless design ensures quiet operation.

8 10/100/1000Mbps RJ45 ports
With four PoE ports, transfers data and power on one single cable
Working with IEEE 802.3af compliant PDs, expands home and office network
802.1p/DSCP QoS enable smooth latency-sensitive traffic
Supports PoE power up to 15.4W for each PoE port
Supports PoE power up to 55W for all PoE ports
Requires no configuration and installation

Specifications

Features
Warranty	60 mo.
Body material	Metal
Switch type	Managed
AC input frequency	50/60 Hz
AC input voltage	100 - 240 V
Fanless
Stackable
10G support
Jumbo frames	16000
Power source	DC/PoE
IGMP snooping
Input current	1.31 A
Rack mounting
Auto MDI/MDI-X
LED indicators
Product colour	Grey
Forwarding rate	11.904 Mpps
Power connector	DC-in jack
Auto-negotiation
DC input voltage	53.5 V
Heat dissipation	225.75 BTU/h
MAC address table	4000 entries
Store-and-forward
Switching capacity	16 Gbit/s
Flow control support
Jumbo frames support
Maximum cable length	100 m
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat3, Cat4, Cat5, Cat5e
Power supply included
Compliance certificates	CE, Federal Communications Commission (FCC), RoHS
Power consumption (max)	75 W
Power over Ethernet (PoE)
Storage temperature (T-T)	-40 - 70 °C
Sustainability compliance
Operating temperature (T-T)	0 - 40 °C
Number of power supply units
Storage relative humidity (H-H)	5 - 90%
MAC address auto-aging supported
Quality of Service (QoS) support
Operating relative humidity (H-H)	10 - 90%
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
MAC address auto-learning supported
Total Power over Ethernet (PoE) budget	64 W
Gigabit Ethernet (copper) ports quantity	8
Power over Ethernet (PoE) ports quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Weight & dimensions
Depth	98 mm
Width	171 mm
Height	27 mm
Packaging
Gross weight	1,25 kg
Gross depth	280 mm
Gross width	223 mm
Gross height	68 mm
Package type	Box
User guide
Cables included	AC
