Cudy 8-Port Gigabit Easy-Managed Switch, GS108E 1.0 L2 Gigabit Ethernet (10/100/1000) Black

Name: Cudy 8-Port Gigabit Easy-Managed Switch, GS108E 1.0 L2 Gigabit Ethernet (10/100/1000) Black
Brand: Cudy
SKU: GS108E
Price: 29.39 EUR
Availability: InStock

Switches and power supplies

29.39 € VAT included

In stock · 10

Cudy 8-Port Gigabit Easy-Managed Switch, GS108E 1.0, Managed, L2, Gigabit Ethernet (10/100/1000), Wall mountable

Secure and High-Performance Switching802.1Q/MTU/Port-Based/Voice VLAN802.1Q VLANs allows creating secure and high-performance network segments across different managed switches. The other MTU/Port-Based VLAN enable simpler local VLAN configuration.DSCP/802.1p/Port-Based QoSDSCP/802.1p QoS identifies DSCP packets in the tranmission and prioritize those latency-sensitive data.Essential Management FeaturesLink AggregationAllows creating multiple LAG groups and multiply the transmission speed of the backbone in your networks.DHCP SnoopingAssign an authorized DHCP server to prevent downtime when other rogue DHCP server connects into the network.IGMP SnoopingIdentifies the multicast groups connected to the switch and sends data to the exact ports instead of broadcasting them.Loop PreventionAutomatically detects network loops and blocks affected ports. Supports STP/RSTP to ensure stable performance in large redundant networks.Web Configuration and SNMP V1/V2Management Made EasyMonitor port status, configure VLAN groups, LAG, DHCP, and more in the intuitive configuration page. The device also features SNMP to allow remote and centralized control.

8× Gigabit Ethernet Ports
Web Management, SNMP
VLAN (802.1Q/MTU/Port-Based)
QoS (802.1p/DSCP/Port-Based)
Port Mirror, Static Aggregation, etc
DHCP Snooping, IGMP Snooping
Loop Detection and Prevention
Desktop, Wall-Mount
138×78×25 mm (5.43×3.07×0.98")

Specifications

Features
Warranty	24 mo.
Body material	Metal
Switch type	Managed
AC input frequency	50/60 Hz
AC input voltage	100 - 240 V
Stackable
10G support
Flash memory	8 MB
Jumbo frames	15000
Power source	DC
Switch layer	L2
VLAN support
DHCP features	DHCP snooping
IGMP snooping
Input current	0.55 A
Rate limiting
LED indicators	Power, Link, Activity
Port mirroring
Product colour	Black
Wall mountable
Forwarding rate	11.904 Mpps
Loop protection
Number of VLANs	4096
Power connector	DC-in jack
DC input voltage	5 V
Number of trunks	4
Surge protection
MAC address table	8192 entries
Switching capacity	16 Gbit/s
Firmware upgradeable
Flow control support
Jumbo frames support
Networking standards	IEEE 802.3x, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az, IEEE 802.1D, IEEE 802.1w, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1ab
Packet buffer memory	0.5 MB
Virtual LAN features	MTU VLAN, Port-based VLAN, Voice VLAN
Web-based management
Cable types supported	Cat3, Cat5, Cat5e, Cat6
Power supply included
Spanning tree protocol
Broadcast storm control
Power consumption (max)	2.75 W
Power saving mode (EEE)
Surge protection voltage	8 kV
Power over Ethernet (PoE)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90%
Quality of Service (QoS) support
Operating relative humidity (H-H)	10 - 90%
Copper ethernet cabling technology	100BASE-TX, 10BASE-T, 1000BASE-T
Gigabit Ethernet (copper) ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Weight & dimensions
Depth	78 mm
Width	138 mm
Height	25 mm
Packaging
Gross weight	0,317 kg
Gross depth	90,5 mm
Gross width	151 mm
Gross height	63 mm
User guide
