Gigabyte

GIGABYTE Z890 UD WIFI6E Motherboard - Supports Intel Core Ultra (Series 2) CPUs, 12+1+2 phases VRM, up to 8800MHz DDR5 (OC), 1xPCIe 5.0 + 2xPCIe 4.0, Wi-Fi 6E, 2.5GbE LAN, USB 4

Motherboards

184.67 € ex VAT

In stock · 4

GIGABYTE Z890 UD WIFI6E Motherboard - Supports Intel Core Ultra (Series 2) CPUs, 12+1+2 phases VRM, up to 8800MHz DDR5 (OC), 1xPCIe 5.0 + 2xPCIe 4.0, Wi-Fi 6E, 2.5GbE LAN, USB 4, Intel, LGA 1851 (Socket V1), Intel Core Ultra (Series 2), LGA 1851, 256 GB, DDR5-SDRAM

Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge

  • Digital 12+1+2+1 Phases 60A DrMOS VRM with Solid Capacitor
  • Reinforced PCIe UD Slot PCIe 5.0 with PCIe EZ-Latch Design
  • PCIe M.2 design (Up to 25110) with Thermal Guard
  • Fully Covered MOSFET Heatsinks
  • 2x2 Wi-Fi 6E with WIFI EZ-Plug Design
  • 2.5GbE LAN, USB 4.0 Type-C, USB 3.2 Gen2 Type-C

Specifications

Features
Battery type CR2032
Warranty 36 mo.
Wireless
Bluetooth version 5.3
Country of origin China
Wi-Fi
BIOS type UEFI AMI
RAID levels 0, 1, 5, 10
ACPI version 5.0
Ethernet LAN
RAID support
Component for PC
Microphone in
TPM connector
Battery weight 3 g
Product colour Black
DirectX version 12.0
Memory channels Dual-channel
S/PDIF out port
Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
BIOS memory size 256 Mbit
Processor socket LGA 1851 (Socket V1)
Clear CMOS button
Clear CMOS jumper
Memory slots type DIMM
Battery technology Lithium-Manganese Dioxide (LiMnO2)
RGB LED pin header
Top Wi-Fi standard Wi-Fi 6E (802.11ax)
USB 2.0 connectors 2
12V power connector
HDMI ports quantity
Motherboard chipset Intel Z890
PC health monitoring Fan, Temperature, Voltage
Audio output channels 7.1 channels
DisplayPorts quantity 2
WLAN controller model Intel Wi-Fi 6E AX211
Number of memory slots 4
On-board graphics card
Processor manufacturer Intel
Supported memory types DDR5-SDRAM
USB 2.0 ports quantity 4
Ethernet interface type 2.5 Gigabit Ethernet
Maximum internal memory 256 GB
Motherboard form factor ATX
Number of M.2 (M) slots 3
Number of battery cells
Number of HDDs supported 7
Ethernet LAN (RJ-45) ports
Lithium weight per battery 0.07 g
Motherboard chipset family Intel
Thunderbolt ports quantity 2
Compatible processor series Intel Core Ultra (Series 2)
EPS power connector (8-pin)
Supported processor sockets LGA 1851
ATX Power connector (24-pin)
Number of SATA III connectors 4
Supported memory clock speeds 5600,5800,6000,6200,6400,6600,6800,7000,7200,7400,7600,7800,7900,7950,8000,8200,8266,8400,8600 MHz
Supported storage drive types HDD & SSD
PCI Express x16 (Gen 4.x) slots 3
PCI Express x16 (Gen 5.x) slots
Total number of SATA connectors 4
Number of storage drives supported 4
Products per shipping (inner) case 1 pc(s)
Supported memory clock speed (max) 8800 MHz
Supported memory module capacities 1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 24GB, 32GB, 40GB, 48GB, 64GB
Supported storage drive interfaces M.2, SATA III
Windows operating systems supported Windows 11 x64
USB 3.2 Gen 1 (3.1 Gen 1) connectors
USB 3.2 Gen 2 (3.1 Gen 2) connectors
System Management BIOS (SMBIOS) version 2.7
Desktop Management Interface (DMI) version 2.7
Maximum internal memory supported by processor 256 GB
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
Technical details
Warranty period 3 year(s)
Weight & dimensions
Depth 244 mm
Width 305 mm
Height 35 mm
Packaging
Gross weight 2,02 kg
Gross depth 270 mm
Gross width 335 mm
Gross height 80 mm
Bundled software Norton® Internet Security (OEM version) LAN bandwidth management software
Batteries included
