GIGABYTE B650E EAGLE WIFI6E Motherboard - AMD Ryzen 9000 Series CPUs, 8+2+2 Phases VRM, up to 8200MHz DDR5 (OC), 1xPCIe 5.0 + 2xPCIe 4.0 M.2, 2.5GbE LAN, WIFI 6E, USB 3.2 Gen 2

Name: GIGABYTE B650E EAGLE WIFI6E Motherboard - AMD Ryzen 9000 Series CPUs, 8+2+2 Phases VRM, up to 8200MHz DDR5 (OC), 1xPCIe 5.0 + 2xPCIe 4.0 M.2, 2.5GbE LAN, WIFI 6E, USB 3.2 Gen 2
Brand: Gigabyte
SKU: B650E EAGLE WF6E
Price: 158.43 EUR
Availability: InStock

Motherboards

158.43 € VAT included

In stock · 6

GIGABYTE B650E EAGLE WIFI6E Motherboard - AMD Ryzen 9000 Series CPUs, 8+2+2 Phases VRM, up to 8200MHz DDR5 (OC), 1xPCIe 5.0 + 2xPCIe 4.0 M.2, 2.5GbE LAN, WIFI 6E, USB 3.2 Gen 2, AMD, Socket AM5, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, Socket AM5, DDR5-SDRAM, 256 GB

Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge technology.

AMD Socket AM5: Supports AMD Ryzen 7000/ Ryzen 8000/ Ryzen 9000 Series Processors
Unparalleled Performance: 8+2+2 Phases Digital VRM Solution
Dual Channel DDR5: 4*SMD DIMMs with AMD EXPO™ & Intel® XMP Memory Module Support
SuperSpeed Storage: 1*PCIe 5.0 + 2*PCIe 4.0 M.2 Connectors
Advanced Thermal Design & M.2 Thermal Guard: To Ensure VRM Power Stability & 25110 M.2 SSD Performance
Fast Networks: Wi-Fi 6E 802.11ax & GbE LAN
WIFI EZ-Plug: Quick and easy design for Wi-Fi antenna installation
Extended Connectivity: DP, HDMI, Rear USB 10Gb/s

Specifications

Features
Battery type	CR2032
Warranty	36 mo.
Wireless
Bluetooth version	5.3
Country of origin	China
HDCP
Wi-Fi
Line-in
BIOS type	UEFI AMI
Audio chip	Realtek ALC897
RAID levels	0, 1, 5, 10
ACPI version	5.0
Cooling type	Passive
Ethernet LAN
HDCP version	2.3
HDMI version	2.1
RAID support
Component for	PC
Microphone in
TPM connector
Battery weight	3 g
LAN controller	Realtek RTL8125
Product colour	Dark brown
DirectX version	12.0
Memory channels	Dual-channel
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
BIOS memory size	256 Mbit
Processor socket	Socket AM5
CPU fan connector
Clear CMOS jumper
Headphone outputs
Memory slots type	DIMM
Power source type	ATX
Unbuffered memory
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Maximum resolution	4096 x 2160 pixels
RGB LED pin header
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
USB 2.0 connectors	2
12V power connector
DisplayPort version	1.4
HDMI ports quantity
Motherboard chipset	AMD B650
PS/2 ports quantity
PC health monitoring	Fan, Temperature, Voltage, Water cooling
WiFi-AP antenna jack	2
Audio output channels	7.1 channels
Front panel connector
WLAN controller model	MediaTek MT7902
Number of memory slots	4
Processor manufacturer	AMD
Supported memory types	DDR5-SDRAM
USB 2.0 ports quantity	4
Ethernet interface type	2.5 Gigabit Ethernet
Maximum internal memory	256 GB
Motherboard form factor	ATX
Number of M.2 (M) slots	3
Number of battery cells
1st M.2 largest key size	22110
2nd M.2 largest key size	22110
3rd M.2 largest key size	22110
Number of HDDs supported	4
Ethernet LAN (RJ-45) ports
Lithium weight per battery	0.07 g
Motherboard chipset family	AMD
Compatible processor series	AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
EPS power connector (8-pin)
Front panel audio connector
Supported processor sockets	Socket AM5
ATX Power connector (24-pin)
Number of CPU fan connectors	2
Number of RGB LED pin headers	4
Number of SATA III connectors	4
Supported memory clock speeds	8200,8000,7950,7900,7800,7600,7200,6800,6600,6400,6200,6000,5600,5200,4800 MHz
Supported storage drive types	HDD & SSD
Number of water pump connectors	2
PCI Express x16 (Gen 3.x) slots	2
PCI Express x16 (Gen 4.x) slots
PCI Express x16 (Gen 5.x) slots
Maximum internal memory per slot	64 GB
Number of chassis fan connectors	4
Number of storage drives supported	7
Products per shipping (inner) case	1 pc(s)
Supported memory clock speed (max)	8200 MHz
Supported storage drive interfaces	M.2, SATA III
Windows operating systems supported	Windows 10 x64, Windows 11 x64
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
1st M.2 highest PCI Express generation	5.0
2nd M.2 highest PCI Express generation	4.0
3rd M.2 highest PCI Express generation	4.0
Number of EPS power connectors (8-pin)
Parallel processing technology support	Not supported
System Management BIOS (SMBIOS) version	2.7
Desktop Management Interface (DMI) version	2.7
Peripheral (Molex) power connectors (4-pin)
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
Technical details
Warranty period	3 year(s)
Weight & dimensions
Depth	244 mm
Width	305 mm
Height	35 mm
Packaging
Gross weight	1,89 kg
Gross depth	270 mm
Gross width	335 mm
Gross height	80 mm
Screws included
Antenna included
Bundled software	Norton® Internet Security (OEM version)
Batteries included
