Dahua Technology WizMind IPC-HDW5559TM-ASE-IL Turret IP security camera Outdoor 2960 x 1668 pixels Ceiling

Name: Dahua Technology WizMind IPC-HDW5559TM-ASE-IL Turret IP security camera Outdoor 2960 x 1668 pixels Ceiling
Brand: Dahua
SKU: IPC-HDW5559TM-ASE-IL-0360B
Price: 384.29 EUR
Availability: InStock

Surveillance cameras and accessories

384.29 € VAT included

In stock · 3

Dahua Technology WizMind IPC-HDW5559TM-ASE-IL, IP security camera, Outdoor, Wired, 56 dB, Ceiling, White

Dahua Technology WizMind IPC-HDW5559TM-ASE-IL. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Turret. Minimum illumination: 0.0005 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 90.3°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Detect distance: 78 m, Observe distance: 31.2 m, Recognize distance: 15.6 m

5-MP 1/2.7" CMOS image sensor, low luminance, and high definition image.
Outputs max. 5 MP (2960 × 1668) @25/30 fps.
Built-in multi-core light, the max. IR distance is 50 m and the max. warm light distance is 50 m.
ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Powered by the Xinghan Large-Scale AI Models-Vision, the camera outstandingly delivers on its object detection, recognition, and scene adaptation functions.
With deep learning algorithm, it supports: AcuPick, video metadata, IVS, face detection, and people counting, etc.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 1 TB Micro SD card; built-in Mic
12 VDC/PoE power supply; ePoE
IP67 protection.

Specifications

Features
Type	IP security camera
Warranty	36 mo.
Wireless
Body material	Metal
Microphone
Chassis type	Turret
Wi-Fi
Mirror
LED type	IR/White
Pan range	0 - 360°
Frame rate	30 fps
Fixed focus
Sensor type	CMOS
Built-in HDD
Ethernet LAN
Night vision
RAM capacity	2000 MB
ROM capacity	4000 MB
Cloud-managed
Dynamic range	56 dB
Mounting type	Ceiling
White balance	Auto, Natural, Street lamp, Outdoor, Manual, Regional custom
Day/night mode
Product colour	White
Detect distance	78 m
Noise reduction
Number of users	20 user(s)
Privacy masking
Video streaming
Bit rate control	Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
HTTPS encryption
Observe distance	31.2 m
Progressive scan
Streaming method	Multicast
Tilt angle range	0 - 80°
Total megapixels	5 MP
Angle of rotation	360°
DC output voltage	12
Digital watermark
Gain control type	Auto/Manual
Identify distance	7.8 m
Power source type	DC, PoE
Alarm input/output
Camera pan control
Fixed focal length	3.6 mm
Maximum resolution	2960 x 1668 pixels
Recognize distance	15.6 m
Camera shutter type	Electronic
Camera tilt control
Optical sensor size	25.4 / 2.7 mm (1 / 2.7")
Placement supported	Outdoor
Alarm input channels
Audio input channels	1.0 channels
Camera shutter speed	1/3 - 1/100000 s
Minimum illumination	0.0005 lx
Alarm output channels
Audio output channels	1.0 channels
Night vision distance	50 m
Card reader integrated
Video motion detection
Audio formats supported	G.711 A-law, G.711 μ-law, PCM, G.726, G.723
Compatible memory cards	MicroSD (TransFlash)
Compliance certificates	Electromagnetic Compatibility (EMC), CE
Connectivity technology	Wired
Maximum aperture number	1.6
Power consumption (max)	13.3 W
Maximum memory card size	1 TB
People counting function
Wide Dynamic Range (WDR)
Closest focusing distance	1.5 m
Storage temperature (T-T)	-40 - 60 °C
Video compression formats	H.265, H.264, H.264H, H.264B, M-JPEG
Ethernet LAN (RJ-45) ports
Noise reduction technology	3D noise reduction
Operating temperature (T-T)	-40 - 60 °C
Power consumption (typical)	4.2 W
Supported network protocols	IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P; Auto Registration
Highlight Compensation (HLC)
Lens viewing angle, diagonal	108.6°
Lens viewing angle, vertical	47.8°
Network access storage (NAS)
Back Light Compensation (BLC)
Lens viewing angle, horizontal	90.3°
Quality of Service (QoS) support
Operating relative humidity (H-H)	0 - 95%
Region of Interest (ROI) encoding
International Protection (IP) code	IP67
Mobile operating systems supported	Android, iOS
Human and vehicle targets classification
Power consumption (Power over Ethernet (PoE))	6.3 W
Intelligent Video Surveillance (IVS) system features	Intrusion, Tripwire, People counting, Human detection, Face detection, Heat map
Technical details
Audio input	RCA
Lens mount interface	M12
Number of video streams	4
Weight & dimensions
Height	105.5 mm
Diameter	12.2 cm
Other
Audio output	RCA
Browser supported	IE: IE 11, Chrome: Chrome 102, Firefox: Firefox 88
Packaging
Gross weight	0,71 kg
Package type	Box
Manual
Number of cameras
