EnGenius Cloud Managed Outdoor AP DBC 11ac Wave2 400+867Mbps 2T2R 4x5dBi RP-SMA GbE PoE.af IP67

Name: EnGenius Cloud Managed Outdoor AP DBC 11ac Wave2 400+867Mbps 2T2R 4x5dBi RP-SMA GbE PoE.af IP67
Brand: EnGenius
SKU: ECW160
Price: 158.13 EUR
Availability: InStock

Routers and signal boosters

158.13 € VAT included

In stock · 10

EnGenius Cloud Managed Outdoor AP DBC 11ac Wave2 400+867Mbps 2T2R 4x5dBi RP-SMA GbE PoE.af IP67, 2.4 GHz, 5 GHz, 867 Mbit/s, SSH, WPA2-AES, WPA2-Enterprise, WPA2-PSK, 10,100,1000 Mbit/s

EnGenius Cloud Managed 11ac Wave 2 2×2 Outdoor Wireless Access Point ECW160 supports MU-MIMO wireless connection, providing up to 867 Mbps in the 5 GHz band and 400 Mbps in the 2.4 GHz band. Its IP67-rated weatherproof and dustproof housing withstands harsh environments, and its Mesh Wireless Support simplifies setup and self-heals. The EnGenius Cloud App allows remote management of an unlimited number of APs.

11ac Wave 2 Wireless Speeds to 867 Mbps on 5 GHz; to 400 Mbps on 2.4 GHz
IP67-Rated Weatherproof & Dustproof Housing Withstands Harsh Environments
Dual-Radio MU-MIMO Improves Performance & Expands User Capacities
Beamforming Optimizes Antenna Signal, Reception & Reliability for Clients
Four (4) Detachable 5 dbi High-Gain, 360° SMA-Type Antennas
Quick-scan device register & configuration and remote monitoring & troubleshooting
Cloud manage an unlimited number of APs from anywhere with the EnGenius Cloud To-Go App
Mesh Wireless Support simplifies setup, optimizes signals & self-heals

Specifications

Features
Warranty	24 mo.
MIMO	Yes
5 GHz	Yes
2.4 GHz	Yes
MIMO type	Multi User MIMO
Placement	Pole, Wall
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK
Antenna type	External
VLAN support	Yes
Certification	FCC, CE, IC
Frequency band	2.4 - 2.482, 5.15 - 5.25, 5.25 - 5.35, 5.47 - 5.725, 5.725 - 5.85 GHz
LED indicators	Yes
Product colour	White
Antenna features	Integrated antenna
Antennas quantity	4
Transmitting power	23 dBmW
Security algorithms	SSH, WPA2-AES, WPA2-Enterprise, WPA2-PSK
Fit AP mode features	Mesh networking
Management protocols	SNMP
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Number of connectors	4
Virtual LAN features	Tagged VLAN
MAC address filtering	Yes
Antenna connector type	SMA
Antenna direction type	Omni-directional
Spread spectrum method	DSSS, OFDM
Ethernet LAN data rates	10,100,1000 Mbit/s
Power consumption (max)	12.6 W
Antenna gain level (max)	5 dBi
Number of SSID supported	8
Power over Ethernet (PoE)	Yes
Storage temperature (T-T)	-40 - 80 °C
Ethernet LAN (RJ-45) ports	1
Maximum data transfer rate	867 Mbit/s
Operating temperature (T-T)	-20 - 60 °C
Wi-Fi Multimedia (WMM)/(WME)	Yes
Quality of Service (QoS) support	Yes
Maximum data transfer rate (5 GHz)	867 Mbit/s
Maximum data transfer rate (2.4 GHz)	400 Mbit/s
Service Set Identifier (SSID) features	Multiple SSIDs
Weight & dimensions
Depth	173.6 mm
Width	111.2 mm
Height	30.3 mm
Packaging
Gross weight	0,58 kg
Gross depth	79 mm
Gross width	247 mm
Gross height	150 mm
Mounting kit	Yes
Quick start guide	Yes
