Manhattan HDMI Splitter 4-Port (Compact), 4K@30Hz, Displays output from x1 HDMI source to x4 HD displays (same output to four displays), AC Powered (cable 0.7m), Black, Three Year Warranty

Name: Manhattan HDMI Splitter 4-Port (Compact), 4K@30Hz, Displays output from x1 HDMI source to x4 HD displays (same output to four displays), AC Powered (cable 0.7m), Black, Three Year Warranty
Brand: Manhattan
SKU: 207706
Price: 45.12 EUR
Availability: InStock

Home Appliances & Electronics

37.29 € ex VAT

In stock · 5

Manhattan HDMI Splitter 4-Port (Compact), 4K@30Hz, Displays output from x1 HDMI source to x4 HD displays (same output to four displays), AC Powered (cable 0.7m), Black, Three Year Warranty, HDMI, 4x HDMI, 4096 x 2160 pixels, Black, Plastic, 15 m

Easily distribute a single Ultra-High-Definition (UHD) signal to multiple displays.The Manhattan 4K 4-Port HDMI Splitter with built-in booster streams a 4K HDMI signal from a single UHD source to up to four UHD displays.Best Possible Image Quality and Easy InstallationFull compliance with HDMI and HDCP 1.4 ensures the Manhattan 4K 4-Port HDMI Splitter provides nothing short of high-quality performance and reliability. It delivers cinematic 4K resolution and supports 3D video, Deep colour, as well as LPCM, DTS and Dolby TrueHD audio. Quickly connect HDMI cables (not included) and the power supply to complete this cost-effective 4K solution - no software or hardware configuration or complicated settings required.

Replicates an Ultra-High-Definition (UHD) digital audio/video signal for up to four UHD HDMI displays
4K@30Hz resolution, full 3D video and Deep colour
Supports video amplifier bandwidth up to 340 MHz and 3.4 Gbps per channel (10.2 Gbps total) for 4Kx2K displays
Supports 36-bit Deep colour (12-bits per channel) and sYCC colour Space
Supports compressed DTS-HD Master Audio, 7.1 surround sound, Dolby TrueHD and uncompressed LPCM 8 channel audio
HDCP compliant
Multiple splitters (five total) may be cascaded up to support 16 4K displays
Works with PlayStation and Xbox game systems, Blu-ray players, set-top boxes, satellite receivers and more
Plug and play
Gold-plated contacts for corrosion-free connections
Three-year warranty

Specifications

Features
Cable length	0,7 m
Body material	Plastic
3D
HDCP
Bandwidth	340 MHz
Video out	4x HDMI
DC-in jack
HDMI version	1.4
Certification	CTS 1.4b, CE, FCC, RoHS2
Plug and Play
LED indicators
Output current	1 A
Output voltage	5 V
Product colour	Black
Video port type	HDMI
Dolby technologies	DTS-HD Master Audio, Dolby TrueHD
Maximum resolution	4096 x 2160 pixels
Video ports quantity	5
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p
Storage temperature (T-T)	-20 - 60 °C
Connector contacts plating	Gold
Maximum operating distance	15 m
Operating temperature (T-T)	0 - 40 °C
Power consumption (typical)	5 W
Operating relative humidity (H-H)	0 - 96%
Technical details
Compliance certificates	RoHS
Weight & dimensions
Depth	81 mm
Width	58 mm
Height	18 mm
Packaging
User guide
AC adapter included
