GIGABYTE AORUS ELITE P1000W ICE Power Supply Unit

Name: GIGABYTE AORUS ELITE P1000W ICE Power Supply Unit
Brand: Gigabyte
SKU: GP-AE1000PM PG5 ICE
Price: 171.26 EUR
Availability: InStock

Power supply units (PSU)

171.26 € VAT included

In stock · 3

GIGABYTE AORUS ELITE P1000W ICE Power Supply Unit, 1000 W, 100 - 240 V, 50/60 Hz, 15 - 6.5 A, Active, 125 W

Ensure reliable and efficient power delivery with GIGABYTE power supplies. Designed for peak performance and durability, our PSUs offer stable and consistent energy to power your high-performance systems. With advanced protections and high-quality components, GIGABYTE power supplies provide the confidence you need for seamless, uninterrupted computing experiences.

ATX 3.0 and PCIe Gen 5.0 ready (compatible with ATX 3.1)
80 PLUS Platinum certified
100% Japanese capacitors
120mm smart Fluid Dynamic Bearing (FDB) fan
Compact design
Fully modular design
Powerful single +12V rail
OVP/OPP/SCP/UVP/OCP/OTP protection
10 years warranty

Specifications

Features
Warranty	120 mo.
AC input frequency	50/60 Hz
AC input voltage	100 - 240 V
Purpose	PC
Hold time	16 ms
Efficiency	92%
ATX version	3.1
Total power	1000 W
Cabling type	Fully-Modular
Cooling type	Active
Fan diameter	12 cm
Fan location	Top
Power factor	0.9
Input current	15 - 6.5 A
On/off switch
Number of fans	1 fan(s)
Product colour	White
Warranty period	10 year(s)
Bearing technology	Ball bearing
Combined power (+5V)	125 W
80 PLUS certification	80 PLUS Platinum
Combined power (+12V)	999.6 W
Combined power (-12V)	3.6 W
PCI Express connector
Combined power (+3.3V)	125 W
Combined power (+5Vsb)	15 W
Max output current (+5V)	25 A
Max output current (+12V)	83.3 A
Max output current (-12V)	0.3 A
Power protection features	Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Max output current (+3.3V)	25 A
Max output current (+5Vsb)	3 A
Floppy disk drive connector
Motherboard power connector	20+4 pin ATX
Floppy drive power connector	2
CPU power connector (4+4 pin)
Power Good signal delay range	100 - 150 ms
ATX power connector (20+4 pin)
Motherboard power cable length	65 cm
Number of SATA power connectors	6
Mean time between failures (MTBF)	100000 h
Power Factor Correction (PFC) type	Active
Power supply unit (PSU) form factor	ATX
PCI Express power connectors (6+2 pin)	6
Peripheral (Molex) power connectors (4-pin)	4
Weight & dimensions
Depth	140 mm
Width	150 mm
Height	86 mm
Packaging
Gross weight	3,73 kg
Gross depth	206 mm
Gross width	340 mm
Gross height	120 mm
Package type	Box
