Epson

Epson ELPDC13 document camera White 25.4 / 2.7 mm (1 / 2.7") CMOS USB 1.1

Various products

538.23 € VAT included

In stock · 5

Epson ELPDC13, 25.4 / 2.7 mm (1 / 2.7"), CMOS, 1920 x 1080 (HD 1080), 30 fps, Auto, Auto

Epson ELPDC13. Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"), Sensor type: CMOS, Supported graphics resolutions: 1920 x 1080 (HD 1080). Digital zoom: 16x, Shooting area (WxD): 297 x 420 mm. Interface: USB 1.1, USB connector type: USB Type-B. Compatible memory cards: SD, Maximum memory card size: 32 GB. Power supply type: AC, Power consumption (typical): 13 W, Power consumption (standby): 0.5 W

  • 25.4 / 2.7 mm (1 / 2.7") CMOS
  • Supported graphics resolutions: 1920 x 1080 (HD 1080)
  • Image freeze
  • Auto focus
  • Interface: USB 1.1
  • White

Specifications

Features
Interface USB 1.1
Warranty 24 mo.
AC input frequency 50 - 60 Hz
AC input voltage 100-240 V
Auto focus
DC-in jack
Sensor type CMOS
Digital zoom 16x
Image freeze
Light source LED
White balance Auto
Mac compatibility
Power supply type AC
Maximum frame rate 30 fps
Parallel connector
USB connector type USB Type-B
Optical sensor size 25.4 / 2.7 mm (1 / 2.7")
Shooting area (WxD) 297 x 420 mm
Light exposure modes Auto
Card reader integrated
Compatible memory cards SD
VGA (D-Sub) input ports
Maximum memory card size 32 GB
VGA (D-Sub) output ports
Operating temperature (T-T) 5 - 35 °C
Power consumption (standby) 0.5 W
Power consumption (typical) 13 W
Supported graphics resolutions 1920 x 1080 (HD 1080)
Mac operating systems supported Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Operating relative humidity (H-H) 20 - 80%
Windows operating systems supported Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista
Technical details
Microphone
Country of origin Philippines
Lamp type LED
Illumination
Image viewer
Split screen
Display modes Microscope
Photo effects Black&White
Product colour White
Cable lock slot
Zoom capability
Bundled software Easy Interactive Tools, TWAIN driver for Epson Document Camera (for Windows)
Special features Auto focus, Freeze, Parallel video output, SD card viewer, Split screen, Zoom
Output resolutions SXGA (1280*1024)/XGA (1024*768)/WXGA 16:10 (1280*800)/WXGA 16:9 (1360*768)/1080p (1920*1080), 480p/720p/1080p
Document size (max) A3
Cable lock slot type Kensington
Vertical rotation angle -90 - 90°
Image quality adjustment Brightness, Contrast
Horizontal rotation angle -90 - 90°
Compatible operating systems Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Mac OS X, Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista
Weight & dimensions
Depth 317 mm
Width 270 mm
Height 447 mm
Packaging
Gross weight 4,58 kg
Gross depth 445 mm
Gross width 235 mm
Gross height 180 mm
Quantity in pack 1 pcs
Manual
Software CD
Carrying case
Cables included AC
AC adapter included
