COUGAR Power Supply ATLAS 750W ATX / 80 Plus Bronze

Name: COUGAR Power Supply ATLAS 750W ATX / 80 Plus Bronze
Brand: Cougar
SKU: CGR BD-750
Price: 65.65 EUR
Availability: InStock

Power supply units (PSU)

54.25 € ex VAT

In stock · 10

COUGAR Power Supply ATLAS 750W ATX / 80 Plus Bronze, 750 W, 100 - 240 V, 50/60 Hz, 10 - 5 A, 10 A, 5 A

COUGAR ATLAS series is high-quality 80 PLUS Bronze certified with flawless power delivery, efficiency, silence and durability. It is the best choice for those who are looking for a high value and reliable power supply.Solid Efficiency Certification with 80 PLUSHighly efficient output and certified with 80 PLUS Bronze. It can provide excellent efficiency to avoid waste and minimize the electric bill.Stable PerformanceDC-DC technology provides a stable voltage with ±2% variation under the standard modes.Ultra DurabilityThe ATLAS is highly durable to provide continuous and flawless power delivery with constantly reliable 105ºC Japanese standby capacitors.Perfect Control Between Noise And Fan SpinningUltra-Silent 120mm COUGAR fan with automatic thermal speed control for an optimal speed-noise ratio.Ample and Black ConnectionThe Atlas series equips 2 CPU connectors for contemporary M/B and CPU settings. Full black and sufficient cable length allow you to install the PC with orderliness and easiness.

80 PLUS Bronze Certified. Up to 87% efficiency power conversion to cut down your electricity bill
Superior fan Curve Tuning. Advanced technology for noise minimization
Single 12V DC Source. Extreme Performance for Powerful Graphics Systems
PF value up to 99%. Provides clean and reliable power
Compatible with the latest PC. TECHNOLOGY created for user with current and next-generation multi-core CPU platforms
Support PCI express 4.0 next-generation graphics cards with 8(6+2) pin PCI-E connector
FULL PROTECTIONS WITH SCP, OCP, OVP, UVP, OPP
80 PLUS Bronze Certified Up to 86% efficiency power conversion to cut down your electricity bill

Specifications

Features
AC input frequency	50/60 Hz
AC input voltage	100 - 240 V
Purpose	PC/Server
Efficiency	86%
Total power	750 W
Cabling type	Non-Modular
Cooling type	Active
Fan diameter	12 cm
Input current	10 - 5 A
On/off switch
Number of fans	1 fan(s)
Product colour	Black
Combined power (+5V)	140 W
80 PLUS certification	80 PLUS Bronze
Combined power (+12V)	750 W
Combined power (-12V)	3.6 W
PCI Express connector
CPU power cable length	60 cm
Combined power (+3.3V)	140 W
Combined power (+5Vsb)	15 W
Compliance certificates	CCC, CE, EAC, Federal Communications Commission (FCC), RoHS
Max output current (+5V)	22 A
Max output current (+12V)	62.5 A
Max output current (-12V)	0.3 A
Power protection features	Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Max output current (+3.3V)	22 A
Max output current (+5Vsb)	3 A
Motherboard power connector	20+4 pin ATX
Maximum input current (@110V)	10 A
Maximum input current (@220V)	5 A
Motherboard power cable length	55 cm
PCI Express power cable length	45 cm
Number of PATA power connectors
Peripheral (Molex) power cable length	450 mm
PCI Express power connectors (6+2 pin)	4
Peripheral (Molex) power connectors (4-pin)	3
Weight & dimensions
Depth	140 mm
Width	150 mm
Height	86 mm
Packaging
Gross weight	2,13 kg
Gross depth	187 mm
Gross width	158 mm
Gross height	165 mm
Package type	Box
