Chieftec Smart 300W power supply unit 20+4 pin ATX TFX Grey

Name: Chieftec Smart 300W power supply unit 20+4 pin ATX TFX Grey
Brand: Chieftec
SKU: GPF-300P
Price: 39.46 EUR
Availability: InStock

Power supply units (PSU)

39.46 € VAT included

In stock · 6

Chieftec Smart 300W, 300 W, 115 - 230 V, 47 - 63 Hz, 6.3 A, Active, 95 W

The latest generation of TFX power supplies comes with a new model: GPF-300P (12V version 2.3). Equipped with both a state-of-the-art interior and 80PLUS® Bronze efficiency, this power supply is ideal for home entertainment systems or small size systems. Compatible with both Intel/AMD processors, featuring with active PFC and a smooth running, temperature-controlled fan, the CHIEFTEC GPF-300P provides reliable performance for enthusiast seeking for efficiency.

300 W 115 - 230 V 47 - 63 Hz
Motherboard power connector: 20+4 pin ATX
PC/Server TFX 80 PLUS Bronze
Active 8 cm
Grey

Specifications

Features
Warranty	24 mo.
AC input frequency	47 - 63 Hz
AC input voltage	115 - 230 V
Purpose	PC/Server
ATX version	2.3
Total power	300 W
Cabling type	Non-Modular
Cooling type	Active
Fan diameter	8 cm
Power factor	0.9
Input current	6.3 A
Number of fans	1 fan(s)
Product colour	Grey
Combined power (+5V)	95 W
80 PLUS certification	80 PLUS Bronze
Combined power (-12V)	3.6 W
CPU power cable length	35 cm
Combined power (+3.3V)	95 W
Combined power (+5Vsb)	10 W
Compliance certificates	RoHS
SATA power cable length	150,350 mm
Max output current (+5V)	15 A
Max output current (-12V)	0.3 A
Power protection features	Over voltage, Overheating, Overload, Short circuit, Under voltage
Max output current (+12V1)	14 A
Max output current (+12V2)	15 A
Max output current (+3.3V)	16 A
Max output current (+5Vsb)	2 A
Motherboard power connector	20+4 pin ATX
Floppy drive power connector	1
EPS power connector (4+4 pin)	Yes
Floppy disk drive cable length	15 cm
Motherboard power cable length	30 cm
Number of SATA power connectors	4
Power Factor Correction (PFC) type	Active
Power supply unit (PSU) form factor	TFX
Peripheral (Molex) power cable length	150,350 mm
Peripheral (Molex) power connectors (4-pin)	2
Weight & dimensions
Depth	175 mm
Width	85 mm
Height	65 mm
Packaging
Gross weight	1,13 kg
