Chieftec ELP-600S power supply unit 600 W 20+4 pin ATX PS/2 Black

Name: Chieftec ELP-600S power supply unit 600 W 20+4 pin ATX PS/2 Black
Brand: Chieftec
SKU: ELP-600S
Price: 47.76 EUR
Availability: InStock

Power supply units (PSU)

39.47 € ex VAT

In stock · 30

Chieftec ELP-600S, 600 W, 200 - 240 V, 47 - 63 Hz, 4.5 A, Active, 120 W

The brand new ELEMENT series combines innovation, high quality, great design and efficiency. With a silent running 12cm fan, the PSU is held in decent black, equipped with long native cables, a power cord, and a solid and eye catching retail box. With an efficiency of over 85% (BRONZE) @230V, the ELEMENT series fulfills the requirement of GREEN IT at an attractive price.

600 W 200 - 240 V 47 - 63 Hz
Motherboard power connector: 20+4 pin ATX
PC/Server PS/2 80 PLUS Bronze
12 cm
Black

Specifications

Features
Warranty	24 mo.
AC input frequency	47 - 63 Hz
AC input voltage	200 - 240 V
Purpose	PC/Server
Efficiency	85%
ATX version	2.3
Total power	600 W
Cabling type	Non-Modular
Fan diameter	12 cm
Power factor	0.9
Input current	4.5 A
Number of fans	1 fan(s)
Product colour	Black
Combined power (+5V)	120 W
80 PLUS certification	80 PLUS Bronze
Combined power (+12V)	552 W
Combined power (-12V)	3.6 W
Combined power (+3.3V)	120 W
Combined power (+5Vsb)	12.5 W
Max output current (+5V)	20 A
Max output current (+12V)	46 A
Max output current (-12V)	0.3 A
Power protection features	Over voltage, Overload, Short circuit, Under voltage
Max output current (+3.3V)	20 A
Max output current (+5Vsb)	2.5 A
Floppy disk drive connector	Yes
Motherboard power connector	20+4 pin ATX
Floppy drive power connector	1
ATX power connector (20+4 pin)	Yes
Number of PATA power connectors	1
Number of SATA power connectors	4
Power Factor Correction (PFC) type	Active
Power supply unit (PSU) form factor	PS/2
PCI Express power connectors (6+2 pin)	2
Peripheral (Molex) power connectors (4-pin)	2
Weight & dimensions
Depth	150 mm
Width	140 mm
Height	87 mm
