ARCTIC TP-4 Premium Performance Thermal Pad

Name: ARCTIC TP-4 Premium Performance Thermal Pad
Brand: Arctic
SKU: ACTPD00065A
Price: 11.24 EUR
Availability: InStock

Coolers

9.29 € ex VAT

In stock · 100

ARCTIC TP-4 Premium Performance Thermal Pad, Thermal pad, 3.4 g/cm³, Grey, -40 - 200 °C, 20 mm, 120 mm

High Performance — Extremely SoftThe silicone-based TP-4 combines high thermal conductivity with extremely low hardness and reliably compensates for manufacturing tolerances between chips.Safe ApplicationElectrically insulating, non-adhesive, and easy to handle — for safe and reliable heat transfer.Minimizing Thermal ResistanceThe thinner the pad, the lower the thermal resistance. Depending on mounting pressure, the TP-4 can be compressed to up to 60% of its original thickness.Bridging Uneven SurfacesAdapts optimally to varying chip heights, air gaps, and uneven surfaces to ensure reliable contact.Available in Various Thicknesses and SizesAvailable in 0.5 mm, 1.0 mm, and 1.5 mm thicknesses as well as multiple sizes. Can be individually cut to size if needed.Stackable Without Performance LossThanks to its low hardness and low interface resistance, multiple pads can be combined without affecting thermal transfer performance.Versatile ApplicationsIdeal for RAM, chipsets, GPUs, consoles, laptops, and many other electronic components. Flexible, vibration-dampening, and easy to cut.

Thermal pad
3.4 g/cm³
Grey
4 pc(s)

Specifications

Features
Type	Thermal pad
Warranty	72 mo.
Country of origin	China
Density	3.4 g/cm³
Product colour	Grey
Operating temperature (T-T)	-40 - 200 °C
Technical details
Warranty period	6 year(s)
Compliance certificates	UL, RoHS
Weight & dimensions
Depth	120 mm
Width	20 mm
Height	0.5 mm
Packaging
Gross weight	0,029 kg
Gross depth	140 mm
Gross width	95 mm
Gross height	0,5 mm
Quantity in pack	4 pcs
